ATA03BB18-L

Name: ATA03BB18-L Artesyn Advanced Energy Board Mount
Brand: Artesyn Advanced Energy
SKU: 58267150
Availability: InStock

DC-DC Converter - 10W - ±12VDC@±416mA - Vin: 9-36VDC - -40 to +90°C - DIP ...

Bekijk gegevensblad

RoHS-conform

TUBE Verpakking

BESCHRIJVING

The ATA03BB18-L is a 10-watt isolated DC-DC converter designed for diverse low-power applications including data communication, telecommunication, computer peripheral equipment, industrial automation, and mobile battery-powered systems. It features an input voltage range of 9–36 VDC with dual ±12V outputs at ±416 mA, achieving 87% efficiency with 1500 VDC I/O isolation and an ultra-wide 4:1 input range. The converter is housed in an ultra-compact mini dual-in-line package measuring 23.8 × 13.7 × 8.0 mm and operates reliably across -40°C to +80°C. Key specifications include ±2.0% voltage tolerance, 0.8% line regulation, 1.0% load regulation, 55 mV noise/ripple, and 370 kHz switching frequency, with hiccup-mode overload and short-circuit protection. The device meets UL/cUL/IEC/EN 62368-1 safety standards, includes CE marking, and is backed by a three-year warranty, making it ideal for applications requiring compact, isolated dual-polarity power supplies with high reliability.

Productkenmerken:

Mogelijke toepassingen:

Zoekwoorden: ATA03BB18L

SPECIFICATIES

Productkenmerk

Attribuutwaarde

Selecteer kenmerk

Producten gevonden: 0

Leverancier:

Artesyn / Advanced Energy

Onderdeelnr.:

ATA03BB18-L

Meeteenheid:

Per Each

RoHS:

Yes

HTS:

8504408500

COO:

ECCN:

EAR99

Standaardverpakking leverancier: Deze informatie wordt verstrekt voor klanten die de voorkeur geven aan het kopen in veelvouden van de standaardverpakkingshoeveelheid van de fabrikant. Minimale bestelhoeveelheden en vereiste bestelveelvouden worden weergegeven bij onze prijs- en beschikbaarheidsinformatie.
