1-5745967-0 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

1-5745967-0

25 RCPT SP/FMS INSRT ...

View Datasheet Ask the Datasheet
RoHS Compliant
TUBE Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

1-5745967-0 is an HD-20 subminiature D connector plug featuring 25 contact positions with a straight posted design and retention 4-40 inserts for secure PCB mounting. The connector has a shell size of 3 with overall dimensions of 2.090 inches (53.09 mm) length and 1.852 inches (47.04 mm) width, with a post length of 0.125 inches (3.18 mm) recommended for PCB board thickness of 0.062–0.093 inches (1.58–2.36 mm). The contacts are finished with duplex plating (gold on mating end, tin on termination end) with nickel underplate, and the housing is constructed from flame-retardant thermoplastic material rated UL 94V-0. This connector is intermediate with any size 20 or 22 subminiature D connectors complying with MIL-C-24308, making it suitable for applications requiring reliable high-density interconnections in industrial, telecommunications, and instrumentation equipment.

Product Highlights:

  • Number of Positions = 25
  • Receptacle
  • PCB Mount Angle = Vertical
  • Product Series = HD 20
  • With Mating Connector Lock

Search Keywords: 157459670

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-5745967-0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Package Type:
TUBE
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
SKT
Termination Method:
Solder
Shell Size:
3
Number of Contacts:
25
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 105 °C
