1658613-2 by te connectivity / amp brand

1658613-2

TE Connectivity / AMP Brand

25 Position D-Sub Plug, Male Pins Connector ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 1658613-2 is a 25-position Amplimite D-sub Plug with phosphor bronze, duplex plated gold on mating end, bright tin on termination end, entire contact under plated nickel, tin-plated steel front shell and black thermoplastic (UL94V-0) housing, cover and cable stabilizer. With standard mounting holes. IDC contact termination. TE Connectivity, the industry leader in AMPLIMITE D-Subminiature solutions, provides a complete range of quality, time-tested D-sub connectors that have become the standard in the D-Sub industry. TE Connectivity's complete line of D-Subminiature Connectors range from right-angle and vertical-posted connectors and cable connectors to the AMPLIMITE .050 Series D-Sub connectors Applications Computers & Computer Peripherals

Product Highlights:

  • Connector
  • Product Series = HDF-20 (Ribbon Cable)
  • Number of Positions = 25
  • Plug
  • With Contacts

Search Keywords: 16586132

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1658613-2
RoHS:
Yes
HTS:
8536694051
COO:
CN
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
40
Package Type:
Tube
Type:
D-Subminiature
Body Orientation:
Right Angle
Mounting:
Cable Mount
Gender:
Pin
Termination Method:
IDT
Shell Size:
3
Number of Contacts:
25
Contact Plating:
Gold Over Nickel,Gold Over Palladium Nickel Over Nickel
Operating Temperature:
-55 to 105 °C

IN STOCK: 10

Ships today, if you order in

Minimum Order: 5

Factory Lead-Time 10 Weeks

Qty
Unit Price
5
$6.11
40
$3.10
80
$3.07
120
$3.02
280
$2.98
520
$2.95
1,000
$2.93
2,520 +
$2.91
Suppliers Standard Package
Log in for special pricing
