782XBXM4L-12D

Power Relay - General Purpose Relays - DPDT - LED clear cover - lock push button - faston terminals - 15A - 24V AC - 2NC + 2NO ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Discontinued
Certificate of Compliance

DESCRIPTION

The Magnecraft / Schneider Electric 782XBXM4L-12D is a high-quality electromechanical relay designed for reliable performance in various industrial applications. With a coil voltage of 12VDC and a coil resistance of 160 Ohm, this double-pole double-throw (DPDT) relay can handle up to 15A of current.Measuring at 27.9x21x46.5mm, this power relay is compact in size, making it suitable for space-constrained installations. It comes with a socket for easy mounting and connection. The 782XBXM4L-12D relay is built to withstand rigorous environments, ensuring long-lasting operation and enhanced durability. It is a dependable choice for controlling power circuits, motors, and other essential equipment.Trust the Magnecraft / Schneider Electric 782XBXM4L-12D relay to provide efficient and reliable switching, making it an essential component for your electrical system.

Search Keywords: 782XBXM4L12D

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Schneider Electric-Legacy Relays
Part No:
782XBXM4L-12D
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
DPDT
Maximum Current Rating:
15 A
Mounting:
Socket
Termination Style:
0.187Quick Connect
Push to Test Button:
Yes
Led Indicator:
Yes
Operating Temperature:
-40 to 70 °C
Coil Resistance:
160 Ohm
Life Cycle:
Discontinued

FREQUENTLY ASKED QUESTIONS

Is 782XBXM4L-12D discontinued?

Yes, 782XBXM4L-12D from Schneider Electric-Legacy Relays is discontinued (end-of-life March 2026). Master Electronics is an authorized distributor and may have remaining stock or a recommended replacement for it.

Is 782XBXM4L-12D RoHS compliant?

Yes, 782XBXM4L-12D is RoHS compliant.

What is the lead time for 782XBXM4L-12D?

The standard lead time for 782XBXM4L-12D is approximately 2 days. In-stock quantities ship from Master Electronics.

  This product is discontinued, but still in stock

IN STOCK: 2,465

Can Ship immediately

Minimum Order Quantity: 10

Multiple: 10

Price (USD)

Qty
Unit Price
10
$23.29
30
$22.91
50
$22.80
100
$22.74
250
$22.69
500
$22.63
1,000 +
$22.57
Supplier's Standard Package
