AZ943-1CH-12DE by american zettler
Image is representational - see manufacturer specifications
American Zettler Authorized Distributor

AZ943-1CH-12DE

15AMP Mini PC Board Relay 12VDC coil SPDT

View Datasheet Ask the Datasheet
RoHS Compliant
Tube Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The AZ943-1CH-12DE is a 15 amp miniature PC board relay with a nominal coil voltage of 12 VDC. The AZ943-1CH-12DE is fully sealed and has a SPDT contact arrangement.

Search Keywords: AZ9431CH12DE

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
American Zettler
Part No:
AZ943-1CH-12DE
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
Tube
Relay Construction:
Non-Latching10725
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
SPDT10703
Mounting:
Through Hole10716
Termination Style:
PC Pin10727
Push to Test Button:
No10724
Led Indicator:
No10708
Operating Temperature:
-40 to 90 °C
Coil Resistance:
400 Ohm

FREQUENTLY ASKED QUESTIONS

Is AZ943-1CH-12DE RoHS compliant?

Yes, AZ943-1CH-12DE is RoHS compliant.

What is the lead time for AZ943-1CH-12DE?

The standard lead time for AZ943-1CH-12DE is approximately 12 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 55,925

Can Ship immediately

Minimum Order Quantity: 25

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
25
$2.062
250
$1.508
500
$1.411
1,000
$1.362
3,000
$1.359
5,000
$1.256
8,000
$1.253
10,000 +
$1.250
Supplier's Standard Package
