CP1-12V by panasonic electronic components
Image is representational - see manufacturer specifications
Panasonic Electronic Components Authorized Distributor

CP1-12V

Relays 12VDC 225Ohm 20(NO)/10(NC)A SPDT(14mm 13mm 9.5mm) THT Automotive Relay Automotive ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The PANASONIC EW/AROMAT CP1-12V Relay is designed specifically for automotive applications. It operates on a 12VDC power supply and has a coil resistance of 225Ohm. This SPDT (Single Pole Double Throw) relay features 20 Normally Open (NO) contacts and 10 Normally Closed (NC) contacts, allowing for versatile switching configurations. The compact dimensions of 14mm x 13mm x 9.5mm make it suitable for space-constrained installations. With its robust through-hole mount design, this automotive relay is built to withstand demanding environments and provide reliable performance.

Search Keywords: CP112V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
CP1-12V
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410020
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Contact Form:
SPDT (1 Form C)
Relay Construction:
Non-Latching
Max Contact Current:
20A (NO) / 10A (NC)
Coil Voltage:
12 VDC
Coil Current:
53.3 mA
Coil Resistance:
225 Ohm
Contact Material:
Silver(Cadmium Free)
Must Operate Voltage:
7.2 VDC
Must Release Voltage:
1 VDC
Operate Time:
10 ms
Seal:
Sealed
Mounting:
Through Hole
Termination Style:
PC Pin
Dimension:
14 x 13 x 9.5 mm
Operating Temperature:
-40 to 85 °C
Packaging:
Tube

FREQUENTLY ASKED QUESTIONS

Is CP1-12V RoHS compliant?

Yes, CP1-12V is RoHS compliant.

What is the lead time for CP1-12V?

The standard lead time for CP1-12V is approximately 24 days. In-stock quantities ship from Master Electronics.

IN STOCK: 16,245

Ships today, if you order in

Minimum Order Quantity: 25

Factory Lead-Time 24 Weeks

Price (USD)

Qty
Unit Price
25
$2.60
100
$2.47
250
$2.35
500
$2.27
1,000
$2.20
3,000
$2.19
5,000
$2.18
8,000 +
$2.17
Supplier's Standard Package
