V7-6C17D8
MICRO SWITCH™ Miniature Basic Switches: V7 Series, Single Pole Double Throw (SPDT), 15.1 A 125, 250, or 277 Vac, Pin Plunger, 170 g to 397 g [6 oz to 14 oz] Maximum Operating Force, 2,9 mm [0.11 in] Mounting Holes, -40 °C to 85 °C [-40 °F to 185 °F] Temperature Range, 4,75 mm x 0,51 mm [0.187 in x 0.02 in] Quick Connect Termination, UL, CSA ...
描述
Snap action switches are highly sensitive switches that respond to very small movements and can rapidly change from one contact position to the other. They are generally used in computer and business equipment, test instruments, medical and dental equipment, communications equipment, gaming equipment, valves, pressure switches and HVAC equipment.
V7-6C17D8 Snap Action Switch from Honeywell has world-wide package size acceptance and a mechanical life of 10M. This Honeywell Switch delivers up to 100K operations at a full load and has UL/CSA and ENEC approvals.
产品亮点:
- The Honeywell Switch is best suited for higher cost-of-failure applications
- It has world-wide package size acceptance
- The Honeywell Switch is designed for 100K operations at a full load or 10M for mechanical life
- Current rating of the Honeywell Switch ranges from 0.1 A to 25 A
- It has UL/CSA and ENEC approvals
潜在应用:
- Appliances
- Vending machines
- Timing devices
- Office equipment
- Computer/business equipment
- Test instruments
- Medical/dental equipment
- Communications equipment
- HVAC equipment
- Manually operated devices
- Valves
- Gaming equipment
- Pressure switches
搜索关键词: V76C17D8
规格
常见问题
V7-6C17D8 是否已停产？
是的，Honeywell 的 V7-6C17D8 已停产（生命周期结束时间：一月 2017）。Master Electronics 是授权分销商，可能仍有剩余库存或可提供推荐的替代产品。
V7-6C17D8 是否符合 RoHS 标准？
是的，V7-6C17D8 符合 RoHS 标准。
V7-6C17D8 的交货期是多少？
V7-6C17D8 的标准交货期约为 3 周。有库存的数量由 Master Electronics 发货。
有存货: 7,333
可立即发货
最小订购数量: 5
工厂交货期 3 周
工具/3D模型
产品指南
数据表
元件时刻 Extended Cut: Honeywell Hazard Switches
Learn more about Honeywell MICRO SWITCH™ Premium Miniature Basic Switches, V7 Series
