V7-1Z10E9 by honeywell
图片仅供参考 - 请查看制造商规格
Honeywell 授权经销商

V7-1Z10E9

MICRO SWITCH™ Miniature Basic Switches: V7 Series, Single Pole Double Throw (SPDT), 25 A 277 Vac, ENEC 20 A 250 Vac, Additional ENEC Coverage @ 5 A Inductive 250 Vac, Pin Plunger, 225 g [7.94 oz] Maximum Operating Force, 3,1 mm [0.12 in] Mounting Holes, -40 °C to 85 °C [-40 °F to 185 °F] Temperature Range, 6,35 mm x 0,81 mm [0.250 in x 0.032 in] Quick Connect Spread Termination, UL, CSA, ENEC ...

查看数据表 询问数据表
符合 RoHS
包装
附件
请求编程报价
合规证书

描述

Snap Action Switch is a type of momentary contact micro switch which operates at a rapid speed as it takes very little force or stimulus to operate. These highly sensitive switches are very often used in timing devices, vending machines, computer and business equipment, test instruments, HVAC equipment's, office equipment's, communications equipment, manually operated devices, valves, gaming equipment's and pressure switches.

V7-1Z10E9 Snap Action Switch from Honeywell features world-wide package size acceptance and has a long mechanical life of up to 10M. This Honeywell Switch is specifically designed to suit higher cost-of-failure applications and delivers up to 100K operations at a full load.

产品亮点:

  • World-wide package size acceptance
  • Current rating ranges from 0.1 A to 25 A
  • UL/CSA and ENEC approvals
  • Best suited for higher cost-of-failure applications
  • Designed for 100K operations at a full load or 10M for mechanical life

潜在应用:

  • Appliances
  • Vending machines
  • Timing devices
  • Office equipment
  • Computer/business equipment
  • Test instruments
  • Medical/dental equipment
  • Communications equipment
  • HVAC equipment
  • Manually operated devices
  • Valves
  • Gaming equipment
  • Pressure switches

搜索关键词: V71Z10E9

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
Honeywell
部件编号:
V7-1Z10E9
计量单位:
每 Each
RoHS:
Yes
HTS:
85365080
COO:
MX
ECCN:
EAR99
供应商标准包装: 此信息提供给偏好按制造商标准包装数量的倍数购买的客户。最小订购数量和要求的订购倍数会与我们的价格和库存信息一起显示。
200
安装方式:
Through Hole
极-位配置:
SPDT
开关配置:
N.O./N.C.
致动器材质/样式:
Plastic/Plunger
触点额定电流 @ 电压:
1491.4 A
最大动作差:
0.25 mm
操作力:
2.21 N
端接方式:
Quick Connect
尺寸:
39.55 x 10.16 x 23.72 mm
本体方向:
Straight
IP等级:
N/A

常见问题

V7-1Z10E9 是否已停产？

是的，Honeywell 的 V7-1Z10E9 已停产（生命周期结束时间：一月 2017）。Master Electronics 是授权分销商，可能仍有剩余库存或可提供推荐的替代产品。

V7-1Z10E9 是否符合 RoHS 标准？

是的，V7-1Z10E9 符合 RoHS 标准。

V7-1Z10E9 的交货期是多少？

V7-1Z10E9 的标准交货期约为 5 周。有库存的数量由 Master Electronics 发货。

有存货: 3,434

可立即发货

最小订购数量: 30

工厂交货期 5 周

价格 (USD)

数量
单价
30
$3.52
50
$3.48
200
$3.35
400
$3.31
600
$3.28
1,000 +
$3.22
