11TW1-3 by honeywell
图片仅供参考 - 请查看制造商规格
Honeywell 授权经销商

11TW1-3

MICRO SWITCH™ Miniature Toggle Switches: TW Series, Single Pole Double Throw (SPDT) 2 Position (On - On), Solder Terminals, 15/32 Inch Bushing, Standard Lever, Military Part Number MS27718-23-1 ...

查看数据表 询问数据表
符合 RoHS
包装
附件
请求编程报价
合规证书

描述

The HONEYWELL part 11TW1-3 is a MICRO SWITCH„¢ Miniature Toggle Switch from the TW Series. It features a Single Pole Double Throw (SPDT) configuration with 2 positions (On - On). The switch has solder terminals for easy and secure connection. It has a 15/32 Inch Bushing and comes with a standard lever. This military-grade switch is equivalent to the part number MS27718-23-1 and is known for its reliable performance and durability.

产品亮点:

  • Qualified to MIL-S-83731
  • Save space and weight
  • SPDT and DPDT circuitry
  • Temperature range: -85 F to +160 F (-65 C to +71 C)
  • Sealed bushing versions
  • Choice of in. or 15/32 in. bushing
  • Color tab available on 15/32 in. bushing
  • UL recognized

潜在应用:

  • Industrial machinery and equipment
  • Military and commercial aviation
  • Construction equipment
  • Test instruments
  • Agricultural machinery
  • Process control
  • Medical instrumentation

搜索关键词: 11TW13

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
Honeywell
部件编号:
11TW1-3
别名/又称:
MS27718-23-1
计量单位:
每 Each
RoHS:
Yes
HTS:
85365009
COO:
US
ECCN:
EAR99
供应商标准包装: 此信息提供给偏好按制造商标准包装数量的倍数购买的客户。最小订购数量和要求的订购倍数会与我们的价格和库存信息一起显示。
1
极-位配置:
1P2T (SPDT)
开关配置:
On None On
触点额定电流 @ 电压:
5 A
致动器样式:
Round Lever
安装方式:
Panel Mount with Threads
螺纹尺寸:
15/32-32
本体方向:
Straight
端子类型:
Solder
尺寸:
14.7 x 13.7 x 48 mm
工作温度:
-65 to 71 °C

FREQUENTLY ASKED QUESTIONS

Is 11TW1-3 RoHS compliant?

Yes, 11TW1-3 is RoHS compliant.

What is the lead time for 11TW1-3?

The standard lead time for 11TW1-3 is approximately 15 days. In-stock quantities ship from Master Electronics.

有存货: 122

可立即发货

已订购: 500   可以发货 11/4/26

工厂交货期 15 周

价格 (USD)

数量
单价
1
$54.36
5
$52.99
10
$50.38
25
$48.39
50
$47.16
100
$46.54
250 +
$45.96
