42547-2

Name: 42547-2 Te Connectivity Amp Brand Ring Lug
Brand: Te Connectivity Amp Brand
SKU: 10388485
Availability: BackOrder

RING 26-22 AWG TPBR ...

Bekijk gegevensblad

RoHS-conform

REEL Verpakking

BESCHRIJVING

The 42547-2 is a machine-applied open barrel ring tongue terminal designed for electrical connections in low-voltage applications. It accommodates 26–22 AWG wire (0.12–0.4 mm² cross-section) and features a stud hole size of 0.254–0.256 mm² (approximately 0.4 mm diameter equivalent). The terminal is constructed from tin-plated brass with a stock thickness of 0.36 mm and dimensions of 4.85 mm width, 3.30 mm length, and 1.90 mm height. This terminal type is commonly used in automotive, telecommunications, and industrial control systems where reliable crimped connections to PCB studs or terminal posts are required, offering excellent corrosion resistance and electrical conductivity through its tin-plated brass composition.

Productkenmerken:

Terminal Shape = Ring Tongue
Receptacle Style = Straight
Barrel Type = Open Barrel
Wire/Cable Type = Regular Wire
Wire Range = 0.12-0.40² [26-22] mm [AWG]

Mogelijke toepassingen:

Zoekwoorden: 425472

SPECIFICATIES

Productkenmerk

Attribuutwaarde

Selecteer kenmerk

Producten gevonden: 0

Leverancier:

TE Connectivity / AMP Brand

Onderdeelnr.:

42547-2

Meeteenheid:

Per Each

RoHS:

Yes

HTS:

8536904000

COO:

ECCN:

EAR99

Rolverpakking: Deze informatie wordt verstrekt voor klanten die de voorkeur geven aan het kopen in veelvouden van de standaardverpakkingshoeveelheid van de fabrikant. Minimale bestelhoeveelheden en vereiste bestelveelvouden worden weergegeven bij onze prijs- en beschikbaarheidsinformatie.
