104068-3 by te connectivity / amp brand
Afbeelding is ter illustratie - zie fabrikantspecificaties
TE Connectivity / AMP Brand Geautoriseerde distributeur

104068-3

30 SYSTEM 50 HDR DRST SHRD ...

Bekijk gegevensblad Stel een vraag aan het gegevensblad
Niet RoHS-conform
Tube Verpakking
Accessoires
Offerte voor programmering aanvragen
Uitgefaseerd en vervangen
Conformiteitscertificaat

BESCHRIJVING

104068-3 is a 30-position double row vertical mount shrouded thru-hole header from the System 50 (AMPMODU) connector series. It features high density contacts spaced on 0.050 x 0.100 inch (1.27 x 2.54 mm) centers with standoffs for ease of cleaning. The housing is made of thermoplastic rated 94V-0, while contacts are copper alloy with gold plating (minimum 0.00033 inch) on the mating area and tin-lead plating (minimum 0.000150 inch) on solder posts, with nickel underplating (minimum 0.000050 inch). This connector is designed for board-to-board applications in computer and personal systems products, offering reliable interconnection with high temperature-tolerant thermoplastic housings.

Productkenmerken:

  • Header Assembly
  • Number of Positions = 30
  • Number of Rows = Dual
  • Shrouded
  • Vertical Mount Angle

Zoekwoorden: 1040683

SPECIFICATIES

Productkenmerk
Attribuutwaarde
Selecteer kenmerk
Producten gevonden: 0
Leverancier:
TE Connectivity / AMP Brand
Onderdeelnr.:
104068-3
Meeteenheid:
Per Each
RoHS:
No
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Standaardverpakking van de leverancier: Het aantal artikelen, de lengte, het gewicht of het volume in de originele verpakking van de leverancier voor efficiënte opslag, verwerking en distributie.
20
Verpakkingstype:
Tube
Type:
Shrouded Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
1.27 mm
Number of Contacts:
30
Maximum Voltage Rating:
30 VAC
Termination Method:
Solder
Operating Temperature:
-65 to 105 °C
Levenscyclus:
Uitgefaseerd en vervangen

VEELGESTELDE VRAGEN

Is 104068-3 uitgefaseerd?

Ja, 104068-3 van Te Connectivity / Amp Brand is uitgefaseerd. Master Electronics is een geautoriseerde distributeur en heeft mogelijk nog voorraad of kan een aanbevolen vervangend product aanbieden.

Is 104068-3 RoHS-conform?

Nee, 104068-3 is niet RoHS-conform.

Wat is de levertijd voor 104068-3?

De standaard levertijd voor 104068-3 is ongeveer 18 weken. Voorraadhoeveelheden worden verzonden vanuit Master Electronics.

  Dit product is niet op voorraad en kan niet worden nabesteld
  Dit product is NIET RoHS-conform.  Bekijk alternatieven
