CN100D05

Name: CN100D05 Sensata Crydom Solid State Relays
Brand: Sensata Crydom
SKU: 55805685
Availability: InStock

SSR Relay - Plug-in/PCB Mount SIP 6mm - 100VDC/6A - 5VDC In - FET Output ...

Bekijk gegevensblad

RoHS-conform

EACH Verpakking

Conformiteitscertificaat

BESCHRIJVING

The CN100D05 is a plug-in/PCB mount solid state relay designed for high-density PCB applications with a 5 mm mini SIP form factor. It provides a maximum load current of 6 A at 0–100 VDC output with a typical on-state voltage drop of 0.1 V at rated current, and features a control voltage range of 3–12 VDC with a nominal input impedance of 450 Ohms. The relay exhibits a maximum turn-on time of 1100 µs and maximum turn-off time of 90 µs, with a maximum PWM frequency of 40 Hz and a maximum blocking voltage of 100 VDC. It operates across an ambient temperature range of -20 °C to 80 °C, has a dielectric strength of 2.5 kV, and is housed in UL 94 V0 material with IP67 encapsulation protection. The CN100D05 is ideal for automation equipment, test equipment, packaging machinery, valve and solenoid control, vending equipment, and medical device applications where reliable DC load switching is required.

Productkenmerken:

Mogelijke toepassingen:

Zoekwoorden: CN100D05

SPECIFICATIES

Productkenmerk

Attribuutwaarde

Selecteer kenmerk

Producten gevonden: 0

Leverancier:

Sensata / Crydom

Onderdeelnr.:

CN100D05

Meeteenheid:

Per Each

RoHS:

Yes

HTS:

8536490080

COO:

ECCN:

EAR99

Standaardverpakking leverancier: Deze informatie wordt verstrekt voor klanten die de voorkeur geven aan het kopen in veelvouden van de standaardverpakkingshoeveelheid van de fabrikant. Minimale bestelhoeveelheden en vereiste bestelveelvouden worden weergegeven bij onze prijs- en beschikbaarheidsinformatie.
