3031416 by phoenix contact
Afbeelding is ter illustratie - zie fabrikantspecificaties
Phoenix Contact Geautoriseerde distributeur

3031416

Ground modular terminal block - connection method: Spring-cage connection - number of connections: 3 - cross section: 0.08 mm² - 6 mm² - AWG: 28 - 10 - width: 6.2 mm - color: green-yellow - mounting type: NS 35/7,5 - NS 35/15 ...

Bekijk gegevensblad
RoHS-conform
Verpakking
Accessoires
Offerte voor programmering aanvragen
Conformiteitscertificaat

BESCHRIJVING

The PHOENIX CONTACT part 3031416 is a ground modular terminal block that is designed to provide a secure and reliable connection. It features a spring-cage connection method, which ensures easy and efficient installation. With a total of 3 connections available, this terminal block can accommodate various wiring needs. It has a cross-section range of 0.08 mm² - 6 mm², making it suitable for a wide range of wire sizes from AWG 28 to 10. The terminal block has a compact width of 6.2 mm, allowing for efficient use of space. The green-yellow color indicates its grounding functionality. It is designed for mounting on NS 35/7,5 or NS 35/15 DIN rails, providing versatility in installation options.

Zoekwoorden: 3031416

SPECIFICATIES

Productkenmerk
Attribuutwaarde
Selecteer kenmerk
Producten gevonden: 0
Leverancier:
Phoenix Contact
Onderdeelnr.:
3031416
Alias/ook bekend als:
ST-4-TWIN-PE
Meeteenheid:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
DE
ECCN:
EAR99
Standaardverpakking leverancier: Deze informatie wordt verstrekt voor klanten die de voorkeur geven aan het kopen in veelvouden van de standaardverpakkingshoeveelheid van de fabrikant. Minimale bestelhoeveelheden en vereiste bestelveelvouden worden weergegeven bij onze prijs- en beschikbaarheidsinformatie.
50
Body Orientation:
Straight

VEELGESTELDE VRAGEN

Is 3031416 RoHS-conform?

Ja, 3031416 is RoHS-conform.

Wat is de levertijd voor 3031416?

De standaard levertijd voor 3031416 is ongeveer 5 dagen. Voorraadhoeveelheden worden verzonden vanuit Master Electronics.

OP VOORRAAD: 275

Kan direct verzenden

Minimale bestelhoeveelheid: 4

Fabriekslevertijd 5 Weken

Prijs (USD)

Aantal
Prijs per eenheid
4
$7.65
25
$7.26
50 +
$6.90
Standaardverpakking van leverancier
Meld u aan voor speciale prijzen Klik voor offerte Prijsmatchverzoek
