M80-8890405

Name: M80-8890405 Harwin Discrete Wire Housing
Brand: Harwin
SKU: 55486521
Availability: InStock

Datamate L-Tek DIL Female Large Bore Crimp Connector, gold clip + gold shell, 2+2 contacts ...

Bekijk gegevensblad

RoHS-conform

BESCHRIJVING

The M80-8890405 is a Datamate 2 mm pitch crimp DIL socket assembly with large bore (22 AWG) designed for reliable electrical interconnection in industrial and electronic equipment. It features a glass-filled PBT UL94V-0 moulding with beryllium copper clips and copper alloy shell, finished with nickel and 0.30 µm gold clip with 0.28 µm gold shell plating. The connector is rated for 3.0 A maximum at 25 °C and 2.2 A at 85 °C, with a working voltage of 120 V AC/DC and voltage proof of 360 V AC/DC, delivering initial contact resistance of 20 mO maximum and insulation resistance of 1000 mO minimum. It withstands 500 mechanical operations with insertion and withdrawal forces of 2.8 N maximum and 1.8 N maximum respectively, and operates reliably across -55 °C to +125 °C. This connector is ideal for applications requiring robust, repeatable mating cycles in harsh environments and demanding electrical performance.

Productkenmerken:

Mogelijke toepassingen:

Zoekwoorden: M808890405

SPECIFICATIES

Productkenmerk

Attribuutwaarde

Selecteer kenmerk

Producten gevonden: 0

Leverancier:

Harwin

Onderdeelnr.:

M80-8890405

Meeteenheid:

Per Each

RoHS:

Yes

HTS:

8536904000

COO:

ECCN:

EAR99

Standaardverpakking leverancier: Deze informatie wordt verstrekt voor klanten die de voorkeur geven aan het kopen in veelvouden van de standaardverpakkingshoeveelheid van de fabrikant. Minimale bestelhoeveelheden en vereiste bestelveelvouden worden weergegeven bij onze prijs- en beschikbaarheidsinformatie.
