M80-0130005

Name: M80-0130005 Harwin
Brand: Harwin
SKU: 55484579
Availability: InStock

The M80-0130005 is a 2mm pitch, fully shrouded, rectangular connector from the M80 series, designed for low-voltage signal interconnections in high-density electronic equipment. ...

Bekijk gegevensblad

RoHS-conform

BESCHRIJVING

The M80-0130005 is a low-frequency signal connector from the M80 series, designed for board-to-board, cable-to-board, and cable-to-cable interconnections. This connector features a 2mm pitch and is intended for use as a low-voltage connector in high-packing-density electronic equipment. It supports a current of up to 3.0A per contact at 25°C when all contacts are loaded and has a working voltage of 800V DC or AC Peak. The connector is built for reliability with a durability rating of 500 mating cycles and an operational temperature range of -55°C to +125°C. With its robust, fully shrouded, and polarized design to prevent mismating, it is suitable for various high-density electronic applications where reliable signal integrity is crucial.

Productkenmerken:

Mogelijke toepassingen:

Zoekwoorden: M800130005

SPECIFICATIES

Productkenmerk

Attribuutwaarde

Selecteer kenmerk

Producten gevonden: 0

Leverancier:

Harwin

Onderdeelnr.:

M80-0130005

Meeteenheid:

Per Each

RoHS:

Yes

HTS:

8536904000

COO:

ECCN:

EAR99

Standaardverpakking leverancier: Deze informatie wordt verstrekt voor klanten die de voorkeur geven aan het kopen in veelvouden van de standaardverpakkingshoeveelheid van de fabrikant. Minimale bestelhoeveelheden en vereiste bestelveelvouden worden weergegeven bij onze prijs- en beschikbaarheidsinformatie.
