RM1A23A50 by carlo gavazzi
Image is representational - see manufacturer specifications
Carlo Gavazzi Authorized Distributor

RM1A23A50

Solid State Relay - SPST - 50 A - 265 VAC - Panel - Screw - Zero Crossing ...

View Datasheet
RoHS Compliant
EACH Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The RM1A23A50 is a 1-phase Solid State Relay with SPST contact, NORYL GFN 1 black housing and aluminum base plate. This panel mount relay features zero crossing switching mode and screw terminals. The zero switching relay with ant parallel thyristor output is the most widely used industrial SSR due to its multiple application possibilities. The relay can be used for resistive, inductive and capacitive loads. The zero switching relay switches ON when the sine curve just crosses zero and switches OFF when the current crosses zero. Direct copper bonding technology LED indicator Built-in varistor secures transient protection Protective touch-safe cover Housing free of molding mass Self-lifting terminals 230VACrms Operational voltage 650Vp Blocking voltage 1.6Vrms On-state voltage drop ≤12ms Pick-up and ≤40ms drop-out response time -20 to 70°C Operating temperature range Applications Industrial

Search Keywords: RM1A23A50

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Carlo Gavazzi
Part No:
RM1A23A50
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8535908085
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Package Type:
EACH
Output Type:
AC
Maximum Output Voltage:
265 V
Maximum Output Current:
50(RMS) A
Output Device:
Thyristor
Input Type:
AC,DC
Input Voltage:
280,48 V
Mounting:
Screw
Circuit Arrangement:
N/A
Dimension:
44.8 x 58.2 x 28.8 mm

FREQUENTLY ASKED QUESTIONS

What replaces RM1A23A50?

The recommended replacement for RM1A23A50 is RM1A23M50 from Carlo Gavazzi, available from Master Electronics.

Is RM1A23A50 RoHS compliant?

Yes, RM1A23A50 is RoHS compliant.

What is the lead time for RM1A23A50?

The standard lead time for RM1A23A50 is approximately 8 days. In-stock quantities ship from Master Electronics.

IN STOCK: 29

Ships today, if you order in

Factory Lead-Time 8 Weeks
