SRN6045TA-6R8M

Name: SRN6045TA-6R8M Bourns Inductor Surface Mount
Brand: Bourns
SKU: 49735932
Availability: InStock

General Purpose Inductor - 6.8uH - 20% - 1 Element - Ferrite-Core - SMD - 2424 ...

Bekijk gegevensblad

RoHS-conform

REEL Verpakking

Conformiteitscertificaat

BESCHRIJVING

SRN6045TA-6R8M is a semi-shielded power inductor from Bourns designed for use in switching power supplies, DC-DC converters, and other power management circuits. The device features a 6.8 µH inductance at 1 MHz with ±20% tolerance, a quality factor (Q) of 15 minimum at 1 MHz, and a self-resonant frequency of 30 MHz typical. It is rated for 3.6 A RMS current with a saturation current of 5.7 A typical and a DC resistance of 34 mO (±20%). The inductor operates over a temperature range of -55°C to +125°C with a 40°C temperature rise at rated current, and is constructed with a ferrite core, enameled copper wire, and magnetic epoxy resin coating. This AEC-Q200 compliant, RoHS-compliant, and halogen-free component is ideal for automotive, industrial, and consumer power conversion applications requiring reliable energy storage and filtering.

Productkenmerken:

Mogelijke toepassingen:

Zoekwoorden: SRN6045TA6R8M

SPECIFICATIES

Productkenmerk

Attribuutwaarde

Selecteer kenmerk

Producten gevonden: 0

Leverancier:

Bourns

Onderdeelnr.:

SRN6045TA-6R8M

Meeteenheid:

Per Each

RoHS:

Yes

HTS:

8504508000

COO:

ECCN:

EAR99

Rolverpakking: Deze informatie wordt verstrekt voor klanten die de voorkeur geven aan het kopen in veelvouden van de standaardverpakkingshoeveelheid van de fabrikant. Minimale bestelhoeveelheden en vereiste bestelveelvouden worden weergegeven bij onze prijs- en beschikbaarheidsinformatie.
