SDR6603-100M
Inductor Power Wirewound 10uH 20% 100KHz 17Q-Factor Ferrite 1.1A 160mOhm DCR T/R ...
BESCHRIJVING
SDR6603-100M is a surface-mount power inductor from Bourns' SDR6603 series, featuring a 10 µH inductance at 100 kHz with ±20% tolerance. The inductor is constructed with a ferrite core, enamelled copper wire, and ceramic base, delivering a maximum RMS current rating of 1.1 A and a saturation current of 1.1 A typical. It exhibits a DC resistance of 0.16 O maximum, a self-resonant frequency of 35 MHz, and operates reliably across a temperature range of -40°C to +125°C with a typical temperature rise of 15°C at rated current. The compact SMD package measures 6.60 mm × 4.45 mm × 2.92 mm (height), making it ideal for space-constrained applications in portable communications equipment, camcorders, LCD TVs, and other DC/DC converter and power supply circuits requiring efficient energy storage and filtering.
Zoekwoorden: SDR6603100M
SPECIFICATIES
VEELGESTELDE VRAGEN
Is SDR6603-100M RoHS-conform?
Ja, SDR6603-100M is RoHS-conform.
Wat is de levertijd voor SDR6603-100M?
De standaard levertijd voor SDR6603-100M is ongeveer 20 dagen. Voorraadhoeveelheden worden verzonden vanuit Master Electronics.
OP VOORRAAD: 0
In bestelling:
1.200
kan verzenden 11-25-26
Minimale bestelhoeveelheid: 600
Meerdere: 600
Fabriekslevertijd 20 Weken
Gegevensblad
