PL182X-301-70

Name: PL182X-301-70 Amphenol Tpi Standard
Brand: Amphenol Tpi
SKU: 60426377
Availability: InStock

High-voltage power connector plug with HVIL (High Voltage Interlock) for 70mm² cable applications. ...

RoHS-conform

BESCHRIJVING

PL182X-301-70 is a PwrLok 10mm 2-pole shielded plug connector designed for high-voltage power applications with integrated HVIL (High Voltage Interlock). This connector features X-key polarization and is designed for 70mm² cable size with a current rating of 250A. It operates at voltages up to 1000 VDC with a dielectric withstanding voltage of 5000 VDC and an operating temperature range of -40°C to +125°C. The connector provides IP67 and IP2X protection class, electromagnetic shielding, and includes an automatic secondary lock for secure mating. Common applications include electric vehicle battery systems and high-power electrical distribution where safety interlocking and reliable high-current connections are required.

Productkenmerken:

Mogelijke toepassingen:

Zoekwoorden: PL182X30170

SPECIFICATIES

Productkenmerk

Attribuutwaarde

Selecteer kenmerk

Producten gevonden: 0

Leverancier:

Amphenol TPI

Onderdeelnr.:

PL182X-301-70

Meeteenheid:

Per Each

RoHS:

Yes

HTS:

8536698000

COO:

ECCN:

EAR99

Standaardverpakking leverancier: Deze informatie wordt verstrekt voor klanten die de voorkeur geven aan het kopen in veelvouden van de standaardverpakkingshoeveelheid van de fabrikant. Minimale bestelhoeveelheden en vereiste bestelveelvouden worden weergegeven bij onze prijs- en beschikbaarheidsinformatie.
