MINT1150A2406K01 by sl power / advanced energy

La imagen es representativa - ver especificaciones del fabricante

MINT1150A2406K01

The MINT1150A2406K01 is a 150W single-output AC/DC power supply providing a 24V output, designed for medical applications in a compact 2" x 4" package. ...

FICHA TÉCNICA

Cumple con RoHS

Certificate of Compliance Guarantee

DESCRIPCIÓN

The MINT1150A2406K01 is a 150W medical-grade AC/DC power supply that delivers a regulated 24V output. It operates over a universal input range of 90-264 VAC and provides an output current of 6.25A with 200LFM airflow or 4.17A with convection cooling. Housed in a compact 2" x 4" x 1.3" package suitable for 1U applications, it features 2 x MOPP input-to-output isolation and is approved to CSA/EN/IEC/UL60601-1, 3rd Edition standards. The unit includes Power Fail and DC OK signals, along with overvoltage and short circuit protection for enhanced reliability. Its high power density, wide operating temperature range, and medical certifications make it ideal for portable medical devices and other space-constrained applications.

Características destacadas del producto:

Aplicaciones potenciales:

Palabras clave de búsqueda: MINT1150A2406K01

ESPECIFICACIÓN

Atributo del producto

Valor de atributo

Seleccionar atributo

Productos Encontrados: 0

Proveedor:

SL Power / Advanced Energy

Nº de pieza:

MINT1150A2406K01

Unidad de medida:

Por Each

RoHS:

Yes

HTS:

8504409520

COO:

ECCN:

EAR99

Paquete estándar del proveedor: Esta información se proporciona a los clientes que prefieren comprar en múltiplos de la cantidad del paquete estándar del fabricante. Las cantidades mínimas de pedido y los múltiplos de pedido requeridos se presentan con nuestra información de precios y d
