RES125E by ohmite
Image is representational - see manufacturer specifications
Ohmite Authorized Distributor

RES125E

Res Wirewound Rheostat 125 Ohm 10% 12.5W 1(Elec)/1(Mech)Turns 3.18mm (33.34 X 22.23 X 26.2mm) Solder Lug Panel Mount ...

View Datasheet Ask the Datasheet
RoHS Compliant
BULK Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The OHMITE RES125E is a robust and reliable wirewound rheostat designed for precise resistance control. With an impedance of 125 Ohms and a tolerance of 10%, this rheostat allows you to adjust and fine-tune the resistance with ease. It features a power rating of 12.5W, ensuring optimal performance even in demanding applications. The RES125E has a 1-turn electrical and mechanical rotation, providing quick and convenient resistance adjustments. Its 3.18mm solder lugs make for secure connections, while the panel mount design allows for easy installation on your desired surface. The compact dimensions of 33.34 x 22.23 x 26.2mm make it ideal for space-constrained projects. Whether for professional or hobbyist use, the OHMITE RES125E is an excellent choice for reliable and precise resistance control.

Search Keywords: RES125E

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Ohmite
Part No:
RES125E
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8533310000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
BULK
Mounting:
Panel Mount
Number of Turns:
1(Elec),1(Mech) Turns
Termination Style:
Solder
Power Rating:
12.5 W
Resistance Value:
125 Ohm
Tolerance:
10 %
Temperature Coefficient:
N/A
Dimension:
33.34 x 22.23 x 26.2 mm
Operating Temperature:
N/A

FREQUENTLY ASKED QUESTIONS

Is RES125E RoHS compliant?

Yes, RES125E is RoHS compliant.

What is the lead time for RES125E?

The standard lead time for RES125E is approximately 14 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 14

Can Ship immediately

MOQ for out of Stock Qty: 2

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
1
$238.04
2
$235.88
3
$234.15
4
$233.56
5 +
$232.98
