ZM50E10F01 by honeywell
La imagen es representativa - ver especificaciones del fabricante

ZM50E10F01

Honeywell

MICRO SWITCH™ Subminiature Basic Switches: ZM Series, Extended Mechanical Life, Single Pole Double Throw (SPDT), 5 A 125/250 Vac, 16,6 mm [0.65 in] Roller Lever Actuator, 146 g [5.15 oz] Maximum Operating Force, Solder Termination, UL, cUL, CE, CQC ...

FICHA TÉCNICA
Cumple con RoHS
embalaje
Accesorios
Solicitar Presupuesto de Programación
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPCIÓN

The HONEYWELL part ZM50E10F01 is a MICRO SWITCHâ„¢ subminiature basic switch from the ZM Series. It features an extended mechanical life and has a single pole double throw (SPDT) configuration. With a 5 A 125/250 Vac rating, this switch is suitable for various applications. It has a 16.6 mm [0.65 in] roller lever actuator and a maximum operating force of 146 g [5.15 oz]. The switch is designed for easy solder termination and is certified by UL, cUL, CE, and CQC for quality and safety assurance.

Características destacadas del producto:

  • Subminiature: 10,6 mm H x 6,4 mm W x 19,8 mm L [0.42 in H x 0.25 in W x 0.78 in L]
  • Choice of low energy or power duty electrical ratings (gold-plated or silver contacts)
  • Single pole double throw (SPDT) circuitry or single pole single throw (SPST) circuitry available
  • Choice of 0.1 A, 5 A or 10.1 A ratings
  • Choice of actuation, termination and operating characteristics
  • Polyamide (nylon) housing material

Aplicaciones potenciales:

  • Appliances
  • Vending machines
  • Timing devices
  • Office equipment
  • Computer/business equipment
  • Test instruments
  • Medical/dental equipment
  • Communications equipment
  • HVAC equipment
  • Manually operated devices
  • Valves

Palabras clave de búsqueda: ZM50E10F01

ESPECIFICACIÓN

Atributo del producto
Valor de atributo
Seleccionar atributo
Productos Encontrados: 0
Proveedor:
Honeywell
Nº de pieza:
ZM50E10F01
Unidad de medida:
Por Each
RoHS:
Yes
HTS:
853650070000
COO:
CN
ECCN:
EAR99
Paquete estándar del proveedor: Esta información se proporciona a los clientes que prefieren comprar en múltiplos de la cantidad del paquete estándar del fabricante. Las cantidades mínimas de pedido y los múltiplos de pedido requeridos se presentan con nuestra información de precios y d
1000
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
N/A/N/A/Polyamide/Roller Lever
Contact Rating @ Voltage:
5@250VAC 30VDC@(cUL/UL) A
Maximum Movement Differential:
0.8 mm
Operating Force:
0.34 N
Termination Style:
Solder
Body Orientation:
Straight
IP Rating:
IP40

EN STOCK: 359

Puede enviar inmediatamente

A la orden: 2.000   puede enviar 8/10/26

Cantidad mínima de pedido: 10

Plazo de entrega de fábrica 11 Semanas

Precio (USD)

Qty
Precio por unidad
10
$2.87
100
$1.96
250
$1.80
500
$1.68
1.000
$1.67
3.000
$1.66
5.000
$1.65
8.000 +
$1.64
Suppliers Standard Package
Log in for special pricing Haga clic para obtener una cotización Price Match Request

Tools/3D Models

Guías de productos
