V7-3E19E9-263 by honeywell
La imagen es representativa - ver especificaciones del fabricante

V7-3E19E9-263

Honeywell

MICRO SWITCH™ Miniature Basic Switches: V7 Series, Single Pole Double Throw (SPDT), 10 A 125, 250, or 277 Vac, ENEC 5 A 250 Vac, Additional ENEC Coverage @ 2 A Inductive 250 Vac, 32,8 mm [1.29 in] Simulated Roller Lever, 33 g [1.16 oz] Maximum Operating Force, 2,9 mm [0.11 in] Mounting Holes, -40 °C to 85 °C [-40 °F to 185 °F] Temperature Range, 6,35 mm x 0,81 mm [0.250 in x 0.032 in] Quick Connect Spread Termination, UL, CSA, ENEC ...

FICHA TÉCNICA
Cumple con RoHS
Tray embalaje
Accesorios
Solicitar Presupuesto de Programación
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPCIÓN

The HONEYWELL part V7-3E19E9-263 is a MICRO SWITCH™ Miniature Basic Switch from the V7 Series. It features a Single Pole Double Throw (SPDT) configuration with a rating of 10 A 125, 250, or 277 Vac and an additional ENEC coverage of 5 A 250 Vac @ 2 A inductive. The switch comes with a 32.8 mm (1.29 in) simulated roller lever and has a maximum operating force of 33 g (1.16 oz). It also has 2.9 mm (0.11 in) mounting holes and can operate within a temperature range of -40 °C to 85 °C (-40 °F to 185 °F).The switch is designed with a 6.35 mm x 0.81 mm (0.250 in x 0.032 in) quick connect spread termination and is certified by UL, CSA, and ENEC for reliability and quality assurance.

Aplicaciones potenciales:

  • Appliances
  • Vending machines
  • Timing devices
  • Office equipment
  • Computer/business equipment
  • Test instruments
  • Medical/dental equipment
  • Communications equipment
  • HVAC equipment
  • Manually operated devices
  • Valves
  • Gaming equipment
  • Pressure switches

Palabras clave de búsqueda: V73E19E9263

ESPECIFICACIÓN

Atributo del producto
Valor de atributo
Seleccionar atributo
Productos Encontrados: 0
Proveedor:
Honeywell
Nº de pieza:
V7-3E19E9-263
Unidad de medida:
Por Each
RoHS:
Yes
HTS:
85365080
COO:
MX
ECCN:
EAR99
Paquete estándar del proveedor: Esta información se proporciona a los clientes que prefieren comprar en múltiplos de la cantidad del paquete estándar del fabricante. Las cantidades mínimas de pedido y los múltiplos de pedido requeridos se presentan con nuestra información de precios y d
200
Tipo de paquete:
Tray
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Steel/Simulated Roller Lever
Contact Rating @ Voltage:
248.57@(CSA/UL) A
Maximum Movement Differential:
0.76 mm
Operating Force:
0.32 N
Termination Style:
Quick Connect
Dimension:
50.04 x 10.16 x 28.93 mm
Body Orientation:
Straight
IP Rating:
N/A

EN STOCK: 2.790

Puede enviar inmediatamente

Cantidad mínima de pedido: 5

Plazo de entrega de fábrica 10 Semanas

Qty
Precio por unidad
5
$4.67
50
$3.45
200
$3.09
400
$3.08
600
$3.06
1.000
$3.05
2.600
$2.83
5.000 +
$2.82
