201LS2 by honeywell
Imagen de referencia - consulte las especificaciones del fabricante
Honeywell Distribuidor Autorizado

201LS2

MICRO SWITCH™ General Purpose Limit Switches: LS Series, Epoxy-Coated Aluminum Housing, Plug-in Body Style, Side Rotary, No Lever, 1NC 1NO Single Pole Double Throw (SPDT) Snap Action, Double Break, 10 A 120, 240, or 480 Vac, Plug-in, Less Base, Requires 18PA1 Terminal Block (0.5 in - 14 NPT) Ordered Separately, Operating Temperature: -29 °C to 71 °C [-20 °F to 160 °F], NEMA 1, 3, 4, 6 and 13 ...

Ver hoja de datos Preguntar a la hoja de datos
Cumple con RoHS
embalaje
Accesorios
Solicitar cotización de programación
Certificado de conformidad

DESCRIPCIÓN

The HONEYWELL part 201LS2 is a MICRO SWITCH„¢ General Purpose Limit Switch, designed for various applications. It features an epoxy-coated aluminum housing and a plug-in body style, ensuring durability and easy installation. With a side rotary configuration and no lever, it offers precise and reliable operation. This switch has a single pole double throw (SPDT) snap action, with a double break design providing excellent electrical performance. It is capable of handling up to 10 A of current at 120, 240, or 480 Vac, making it suitable for a wide range of voltage requirements.Please note that this switch does not come with a base and requires the separate purchase of an 18PA1 Terminal Block (0.5 in - 14 NPT). The operating temperature range of this switch is from -29 °C to 71 °C [-20 °F to 160 °F], allowing it to operate reliably in various environmental conditions.The HONEYWELL part 201LS2 is compliant with NEMA 1, 3, 4, 6, and 13 standards, providing protection against dust, water, and corrosion. It is a dependable and versatile limit switch, ideal for use in a wide range of industrial and commercial applications.

Características destacadas:

  • Mode of operation is field adjustable
  • NEMA 1, 3, 4, 6, and 13
  • Wide choice of heads and actuators
  • Variety of operating characteristics
  • Captive screws
  • UL and CSA approved parts available

Aplicaciones potenciales:

  • Machine tools
  • Conveyors
  • Material handling
  • Metal fabrication equipment
  • Lift trucks

Palabras clave de búsqueda: 201LS2

ESPECIFICACIONES

Atributo del producto
Valor del atributo
Seleccionar atributo
Productos Encontrados: 0
Proveedor:
Honeywell
Nº de pieza:
201LS2
Unidad de medida:
Por Each
RoHS:
Yes
HTS:
85365080
COO:
MX
ECCN:
EAR99
Empaque estándar del proveedor: Esta información se proporciona a los clientes que prefieren comprar en múltiplos de la cantidad del paquete estándar del fabricante. Las cantidades mínimas de pedido y los múltiplos de pedido requeridos se presentan con nuestra información de precio y disponibilidad.
10
Tipo:
Compact
Estilo de actuador:
Side Rotary
Configuración de Polos y Vías:
SPDT
Configuración del Interruptor:
N.O./N.C.
Fuerza de operación:
N/A
Dimensión:
87.63 mm
Corriente Nominal Máxima:
0.8@115VDC A
Tipo de Terminal:
Conduit
Norma NEMA como grado de protección del gabinete:
1, 3, 4, 6, 13
Orientación del Cuerpo:
Right Angle

FREQUENTLY ASKED QUESTIONS

Is 201LS2 RoHS compliant?

Yes, 201LS2 is RoHS compliant.

What is the lead time for 201LS2?

The standard lead time for 201LS2 is approximately 18 days. In-stock quantities ship from Master Electronics.

EN STOCK: 60

Envío today, Introduzca el valor de la configuración.

Plazo de entrega de fábrica 18 Semanas

Precio (USD)

Cant.
Precio unitario
1
$406.39
3
$402.43
5 +
$388.52
Inicie sesión para precios especiales Haga clic para solicitar una cotización Solicitud de igualación de precio
