La imagen es representativa - ver especificaciones del fabricante

SM4265

Fairview Microwave

SMA Male (Plug) to N Female (Jack) Adapter, Passivated Stainless Steel Body, 1.25 VSWR ...

FICHA TÉCNICA

RoHS no cumple con RoHS

Bag embalaje

DESCRIPCIÓN

SM4265 is an SMA male to N female RF adapter from Fairview Microwave designed to enable connections between two incompatible connector types. The adapter operates across a frequency range from DC to 18 GHz with excellent VSWR performance of 1.25:1 maximum and 50 ohm impedance. It features gold-plated beryllium copper contacts with 1.3 µm minimum plating thickness, PTFE insulation, and passivated stainless steel body materials, with an operating voltage rating of 335 Vrms AC and dielectric withstand voltage of 1,000 Vrms AC. The adapter measures 1.28 inches (32.51 mm) in length, weighs 0.0585 lbs (26.54 g), and operates reliably across a temperature range of -45°C to +120°C. This adapter is ideal for general-purpose RF testing, equipment protection during frequent connect/disconnect cycles, and enabling between-series connections in microwave and millimeter-wave applications.

Características destacadas del producto:

Aplicaciones potenciales:

Palabras clave de búsqueda: SM4265

ESPECIFICACIÓN

Atributo del producto

Valor de atributo

Seleccionar atributo

Productos Encontrados: 0

Proveedor:

Fairview Microwave

Nº de pieza:

SM4265

Unidad de medida:

Por Each

RoHS:

HTS:

8536694010

COO:

ECCN:

EAR99

Paquete estándar del proveedor: Esta información se proporciona a los clientes que prefieren comprar en múltiplos de la cantidad del paquete estándar del fabricante. Las cantidades mínimas de pedido y los múltiplos de pedido requeridos se presentan con nuestra información de precios y d
