SRR1210-221M by bourns
Imagen de referencia - consulte las especificaciones del fabricante

SRR1210-221M

Bourns

The SRR1210-221M is a shielded, surface-mount power inductor with an inductance of 220 µH. ...

FICHA TÉCNICA
Cumple con RoHS
REEL embalaje
Accesorios
Solicitar Presupuesto de Programación
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Garantía del certificado de conformidad

DESCRIPCIÓN

The SRR1210-221M is a shielded SMD power inductor designed for power supply applications. It provides an inductance of 220 µH with a ±20% tolerance, a maximum DC resistance of 315 mΩ, and a typical self-resonant frequency of 1.8 MHz. The component is rated for a saturation current (Isat) of 1.5 A and an RMS current (Irms) of 1.7 A. With an operating temperature range of -40°C to +125°C, this RoHS-compliant inductor is robust for various environments. It is well-suited for use in the input/output stages of DC/DC converters and power supplies for portable communication equipment, camcorders, and LCD TVs.

Palabras clave de búsqueda: SRR1210221M

ESPECIFICACIÓN

Atributo del producto
Valor del atributo
Seleccionar atributo
Productos Encontrados: 0
Proveedor:
Bourns
Nº de pieza:
SRR1210-221M
Unidad de medida:
Por Each
RoHS:
Yes
HTS:
8504500000
COO:
CN
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
250
Tipo de paquete:
REEL
Inductancia:
220 uH
Tipo:
Power
Impedancia:
N/A
Tolerancia:
20 %
Tecnología:
Wirewound
Corriente DC Máxima:
1.7 A
Resistencia DC máxima:
0.315 Ohm
Temperatura de Funcionamiento:
-40 to 125 °C
Embalaje:
Tape and Reel
Tipo de Protección:
Shielded

EN STOCK: 0

A la orden: 2.500   puede enviar 8/24/26

Cantidad mínima de pedido: 250

Múltiple: 250

Plazo de entrega de fábrica 20 Semanas

Precio (USD)

Qty
Precio unitario
250
$0.882
500
$0.833
1.000
$0.815
2.500
$0.747
5.000
$0.746
7.500
$0.744
10.000
$0.732
15.000 +
$0.695
Reel Package
Log in for special pricing Haga clic para solicitar una cotización Price Match Request
