3260W-1-502 by bourns
La imagen es representativa - ver especificaciones del fabricante

3260W-1-502

Bourns

Res Wirewound Trimmer 5K Ohm 5% 0.25W(1/4W) 11(Elec)Turns 1.78mm (6.35 X 4.32 X 7.24mm) Pin Thru-Hole Tube ...

FICHA TÉCNICA
Cumple con RoHS
TUBE embalaje
Accesorios
Solicitar Presupuesto de Programación
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPCIÓN

The 3260W-1-502 is a 1/4" square Trimpot trimming potentiometer manufactured by Bourns, designed for precision adjustment applications in industrial environments. This multiturn wirewound device features a 5,000 ohm resistance value with ±5% tolerance, 0.34% nominal resolution, and an 11-turn adjustment angle for fine control. The potentiometer operates across a wide temperature range of -65°C to +150°C with a temperature coefficient of ±70 ppm/°C, and delivers 0.25 watts at 85°C. It is sealed, RoHS compliant, and listed on the QPL for MIL-R-27208 style RT26, with dielectric strength rated at 600 VAC at sea level and 1,000 megohms minimum insulation resistance. The device is ideal for circuit trimming, calibration, and processing applications where reliable, repeatable adjustment and environmental durability are required.

Palabras clave de búsqueda: 3260W1502

ESPECIFICACIÓN

Atributo del producto
Valor de atributo
Seleccionar atributo
Productos Encontrados: 0
Proveedor:
Bourns
Nº de pieza:
3260W-1-502
Unidad de medida:
Por Each
RoHS:
Yes
HTS:
8533310000
COO:
MX
ECCN:
EAR99
Paquete estándar del proveedor: Esta información se proporciona a los clientes que prefieren comprar en múltiplos de la cantidad del paquete estándar del fabricante. Las cantidades mínimas de pedido y los múltiplos de pedido requeridos se presentan con nuestra información de precios y d
25
Tipo de paquete:
TUBE
Mounting:
Through Hole
Number of Turns:
11(Elec) Turns
Termination Style:
Pin
Power Rating:
0.25 (1/4) W
Resistance Value:
5 KOhm
Tolerance:
5 %
Temperature Coefficient:
±70 ppm/°C
Dimension:
6.35 x 4.32 x 7.24 mm
Operating Temperature:
-65 to 150 °C
Switch Option:
No
Number of Elements:
1

EN STOCK: 108

Buques today, Si realiza un pedido en

MOQ para cantidad agotada: 13

Plazo de entrega de fábrica 7 Semanas

Precio (USD)

Qty
Precio por unidad
1
$38.07
5
$37.98
10
$37.88
13
$37.79
25
$29.48
38
$27.15
50 +
$26.61
