SBS75GBLK-BK by anderson power products
Imagen de referencia - consulte las especificaciones del fabricante
Anderson Power Products Distribuidor Autorizado

SBS75GBLK-BK

SBS® 75G Standard Housing - Black ...

Ver hoja de datos Preguntar a la hoja de datos
Cumple con RoHS
Bulk embalaje
Accesorios
Solicitar cotización de programación
Certificado de conformidad

DESCRIPCIÓN

SBS®75G are available in wire-to-wire and wire-to-board configurations providing power contacts rated up to 110 amps. The SBS®75G features a third first-mate last-break ground or power contact. All contact positions are rated for circuit interruption (hot plugging).

Palabras clave de búsqueda: SBS75GBLKBK

ESPECIFICACIONES

Atributo del producto
Valor del atributo
Seleccionar atributo
Productos Encontrados: 0
Proveedor:
Anderson Power Products
Nº de pieza:
SBS75GBLK-BK
Alias/también conocido como:
SBS75GBLK
Unidad de medida:
Por Each
RoHS:
Yes
HTS:
8538907080
COO:
CN
ECCN:
EAR99
Empaque estándar del proveedor: Esta información se proporciona a los clientes que prefieren comprar en múltiplos de la cantidad del paquete estándar del fabricante. Las cantidades mínimas de pedido y los múltiplos de pedido requeridos se presentan con nuestra información de precio y disponibilidad.
250
Tipo de encapsulado:
Bulk
Montaje:
Cable Mount
Orientación del Cuerpo:
Straight
Género:
RCP
Método de terminación:
Crimp
Número de Contactos:
3
Tensión Máxima Nominal:
80 V
Corriente Nominal Máxima:
20 A
Temperatura de Funcionamiento:
-20 to 105 °C

PREGUNTAS FRECUENTES

¿Cumple SBS75GBLK-BK con la normativa RoHS?

Sí, SBS75GBLK-BK cumple con la normativa RoHS.

¿Cuál es el plazo de entrega de SBS75GBLK-BK?

El plazo de entrega estándar de SBS75GBLK-BK es de aproximadamente 2 semanas. Las cantidades disponibles se envían desde Master Electronics.

EN STOCK: 630

Puede enviar inmediatamente

A la orden: 5.000   puede enviar 11/13/26

Cantidad mínima de pedido: 5

Plazo de entrega de fábrica 2 Semanas

Precio (USD)

Cant.
Precio unitario
5
$6.358
50
$5.352
100
$5.047
250
$4.595
500
$4.506
1.000
$4.291
2.500
$4.280
5.000 +
$4.269
Embalaje estándar del proveedor
Inicie sesión para precios especiales
