8534-4500PL

Name: 8534-4500PL
Brand: 3M Interconnect Solutions
SKU: 45433489
Price: 39.8 USD
Availability: InStock

3M Interconnect Solutions

Polarized Boardmount Socket (34 pos) .100 centerline straight solder tails | 3M 8534-4500PL ...

FICHA TÉCNICA

Cumple con RoHS

DESCRIPCIÓN

8534-4500PL is a 34-pin polarized boardmount socket from the 3M 8500 Series, featuring centerbump polarization with 0.100" x 0.100" pitch and straight solder tails. The socket is constructed with a UL 94V-0 rated glass-filled polyester (PBT) body in gray color, and features copper alloy contacts with 2 µm nickel underplating and 0.3 µm gold in the wiping area. It offers a current rating of 1 A, insulation resistance greater than 1 × 10?O at 500 VDC, and withstanding voltage of 1,000 V RMS at sea level. The connector operates over a temperature range of -55°C to 105°C and includes board retention features for secure mounting during flow soldering operations. This socket is designed to mate with low profile shrouded headers and is ideal for applications requiring reliable board-to-board interconnections.

Características destacadas del producto:

Aplicaciones potenciales:

Palabras clave de búsqueda: 85344500PL

ESPECIFICACIÓN

Atributo del producto

Valor de atributo

Seleccionar atributo

Productos Encontrados: 0

Proveedor:

3M Interconnect Solutions

Nº de pieza:

8534-4500PL

Alias/alias:

7100007051

Unidad de medida:

Por Each

RoHS:

Yes

HTS:

8536694040

COO:

ECCN:

EAR99

Paquete estándar del proveedor: Esta información se proporciona a los clientes que prefieren comprar en múltiplos de la cantidad del paquete estándar del fabricante. Las cantidades mínimas de pedido y los múltiplos de pedido requeridos se presentan con nuestra información de precios y d
