RN102-1.5-02-1M6 by te connectivity / schaffner emc

RN102-1.5-02-1M6

TE Connectivity / SCHAFFNER EMC

Choke - Current-Compensated - 1.6 mH - 1.5 A - RN Series. ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The RN102-1.5-02-1M6 from Schaffner is a current compensated common mode choke. It is an attenuating common mode or asymmetric (P/N –> E) interference signal by being connected in series with phase and neutral lines of an AC powerline input. Symmetrical components of noise are also attenuated by leakage inductance (stray inductance) of the windings. This choke is typically used in conjunction with suppression capacitors. It has high saturation resistance and excellent thermal behaviour. It is typically used in switch mode power applications, suppressing common mode interference levels, EMI input filters, suppression equipment with no earth connection and phase angle control circuits in combination with saturating chokes. This common mode choke is approved by VDE, UL 1283 and IEC/EN 60938-1 standards.

Search Keywords: RN10215021M6

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / SCHAFFNER EMC
Part No:
RN102-1.5-02-1M6
Alias/AKA:
816486-SF
RoHS:
Yes
HTS:
8504508000
COO:
TH
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
40
Package Type:
Tube
Family:
RN
Attenuation:
N/A
Impedance:
N/A
Dimension:
14.3mm x 14.3mm x 9.3 mm
Configuration:
Dual

IN STOCK: 1,041

Ships today, if you order in

Minimum Order: 40

Multiple: 40

Factory Lead-Time 12 Weeks

Qty
Unit Price
40
$1.275
280
$1.125
520
$1.062
1,000
$1.000
2,520
$0.925
5,000
$0.921
7,520
$0.916
10,000 +
$0.911
Suppliers Standard Package
Log in for special pricing
Please Note: Tariffs may apply for U.S. shipments
