TXS2SA-9V

Signal Relay 9VDC 1A DPDT( (15mm 9.4mm 8.4mm)) SMD Automotive ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

TXS2SA-9V is a single-side stable electromagnetic relay designed for low-power switching applications with a nominal coil voltage of 9V DC. The relay achieves ultra-high sensitivity at 50 mW nominal operating power through a highly efficient polar magnetic circuit with seesaw balance mechanism, delivering a minimum operating power of 32 mW. It features 2 Form C contacts with gold-clad twin crossbar contacts for high contact reliability, maximum initial contact resistance of 100 mO, and a nominal switching capacity of 30V DC at 1A resistive load. The compact surface-mount design measures 15.0 mm × 7.4 mm × 8.2 mm, with outstanding surge resistance rated at 1,500V (10×160 µs) between open contacts per FCC Part 68. This relay is ideal for telecommunications, automotive control systems, and low-power switching applications requiring high reliability and compact form factor.

Search Keywords: TXS2SA9V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
TXS2SA-9V
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410020
COO:
JP
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
40
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
9 V
Contact Arrangement:
DPDT
Maximum Current Rating:
1 A
Mounting:
Surface Mount
Operating Temperature:
-40 to 70 °C
Dimension:
15 x 9.4 x 8.2 mm
Termination Style:
Gull Wing
Coil Current:
5.6 mA
Contact Form:
2 Form C

FREQUENTLY ASKED QUESTIONS

Is TXS2SA-9V RoHS compliant?

Yes, TXS2SA-9V is RoHS compliant.

What is the lead time for TXS2SA-9V?

The standard lead time for TXS2SA-9V is approximately 52 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 479

Can Ship immediately

Minimum Order Quantity: 40

Multiple: 40

Factory Lead-Time 52 Weeks

Price (USD)

Qty
Unit Price
40
$3.13
80
$3.02
280
$2.82
520
$2.72
1,000
$2.23
2,520
$2.11
5,000
$2.01
7,520 +
$1.99
Supplier's Standard Package
