V23079D1005B301 by te connectivity / p-b brand
Image is representational - see mfr. specs

V23079D1005B301

TE Connectivity / P&B Brand

Signal Relay - 2 form C - Bistable, 1 coils - Contacts: AgNi +Au, 2A 250VAC - Coil: 24VDC, 8228 ohm - PCB Thru Hole ...

Datasheet
RoHS Compliant
Reel Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

TE Connectivity / P&B Brand part V23079D1005B301 is a high-quality signal relay designed for use in various applications such as automotive and medical industries. This relay operates on a 24VDC voltage with a maximum current rating of 2A. It features a DPDT (Double Pole Double Throw) configuration, providing reliable switching between two separate circuits. With its compact dimensions of 14.5x9.4x10.4mm and surface-mount design, this relay offers easy installation and efficient space utilization. Whether used in vehicle control systems or medical devices, this TE Connectivity / P&B relay delivers exceptional performance and durability.

Product Highlights:

  • V23079 / P2 Relay Series
  • DC Actuating System
  • Input Voltage = 24 VDC
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Current Rating = 2 Amps.

Search Keywords: V23079D1005B301

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
V23079D1005B301
Alias/AKA:
5-1393788-8
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536490080
COO:
CZ
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
400
Package Type:
Reel
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
DPDT
Maximum Current Rating:
2 A
Mounting:
Surface Mount
Operating Temperature:
-40 to 85 °C
Dimension:
14.5 x 10.4 x 9.4 mm
Termination Style:
Gull Wing
Coil Current:
5.83 mA
Contact Form:
2 Form C

IN STOCK: 34,436

Can Ship immediately

On Order: 50,000   can ship 4/14/27
On Order: 50,000   can ship 4/21/27

Minimum Order Quantity: 100

Factory Lead-Time 50 Weeks

Qty
Unit Price
100
$1.28
400
$1.24
800 +
$1.12
Reel Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
