EG2211A by e-switch
Image is representational - see manufacturer specifications
E-Switch Authorized Distributor

EG2211A

Slide Switch - DPDT - 200mA - 30VDC - Standard Actuator - 2.00mm Actuator Length - PC Pin - Through Hole - Right Angle.

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The EG2211A slide switch has copper alloy contacts with silver finish. Typically used for: computer servers/peripherals, consumer electronics, instrumentation, test and measurement. Operating temperature range is from -20°C to 70°C.

Search Keywords: EG2211A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
E-Switch
Part No:
EG2211A
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Mounting:
PCB Through Hole
Body Orientation:
Right Angle
Actuator Style:
Side Slide
Pole Throw Configuration:
DPDT
Switch Configuration:
N/A
Contact Rating @ Voltage:
N/A
Contact Plating:
Silver
Operating Temperature:
-20 to 70 °C
Termination Style:
PC Pins
Dimension:
10 x 8 x 3.7 mm

FREQUENTLY ASKED QUESTIONS

Is EG2211A RoHS compliant?

Yes, EG2211A is RoHS compliant.

What is the lead time for EG2211A?

The standard lead time for EG2211A is approximately 15 days. In-stock quantities ship from Master Electronics.

IN STOCK: 2,950

Can Ship immediately

MOQ for In Stock Qty: 50

MOQ for out of Stock Qty: 1000

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
50
$0.9535
250
$0.9511
500
$0.9488
1,000
$0.9464
2,000
$0.5824
3,000
$0.4611
4,000 +
$0.4518
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
