640389-3 by te connectivity / amp brand

640389-3

TE Connectivity / AMP Brand

03P MTA156 HDR ASSY SQ R/A F/L ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / AMP Brand part 640389-3 is a 3-position MTA156 header assembly with a square design, right-angle orientation, and friction lock feature. This assembly is ideal for applications where a reliable electrical connection is required in a space-saving design.

Product Highlights:

  • MTA-156 Connectors
  • Number of Positions = 3
  • Mating Type = Header
  • Wire-to-Board Application
  • 3.96 mm Contact Centerline Spacing

Search Keywords: 6403893

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
640389-3
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
2500
Package Type:
Pack
Type:
Wire to Board
Body Orientation:
Right Angle
Gender:
HDR
Mounting:
Through Hole
Pitch:
3.96 mm
Number of Contacts:
3
Maximum Voltage Rating:
600 VAC
Maximum Current Rating:
7/Contact A
Termination Method:
Solder
Operating Temperature:
-55 to 105 °C

IN STOCK: 66

Can Ship immediately

On Order: 9,421   can ship 1/28/26

Minimum Order: 50

Factory Lead-Time 14 Weeks

Qty
Unit Price
50
$0.3226
500
$0.2359
1,000
$0.2347
2,500
$0.2244
5,000
$0.2215
7,500
$0.2204
10,000
$0.2193
15,000 +
$0.2182
Suppliers Standard Package
Log in for special pricing
Please Note: Tariffs may apply for U.S. shipments
