ERZ-V05D391 by panasonic
Image is representational - see mfr. specs

ERZ-V05D391

Panasonic

The ERZ-V05D391 is a ZNR transient/surge absorber with a nominal varistor voltage of 390V designed for overvoltage protection. ...

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The ERZ-V05D391 is a radial leaded, V-series ZNR transient/surge absorber designed to protect electronic circuits from overvoltage events. It features a nominal varistor voltage of 390V, a maximum allowable voltage of 250V ACrms or 320V DC, and a maximum clamping voltage of 675V at 5A. This compact device can handle a maximum peak surge current of 800A (8/20µs, 1 time) and has a maximum capacitance of 80 pF. It operates over a temperature range of -40°C to 85°C. Due to its specifications, it is well-suited for surge protection in telephone line applications, as well as in consumer, communication, and controller electronics.

Search Keywords: ERZV05D391

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic
Part No:
ERZ-V05D391
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8533404000
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Varistor Voltage:
390 V
Clamping Voltage:
675 V
Clamping Current:
5 A
Mounting:
Through Hole
Dimension:
5.4 x 10 x 7 mm
Maximum AC Voltage Rating:
250 V
Maximum DC Voltage Rating:
320 V
Maximum Surge Current:
800 A
Lead Style:
Radial
Lead Pitch:
5 mm
Tolerance Voltage:
N/A

IN STOCK: 12,000

Can Ship immediately

Minimum Order Quantity: 1000

Multiple: 1000

Factory Lead-Time 18 Weeks

Qty
Unit Price
1,000
$0.0937
3,000
$0.0897
5,000
$0.0877
8,000
$0.0849
25,000
$0.0839
50,000
$0.0835
100,000
$0.0831
150,000 +
$0.0826
Suppliers Standard Package
