5745784-4 by te connectivity / amp brand

5745784-4

TE Connectivity / AMP Brand

D Sub Connector - DB37 - 37 Contacts - Receptacle - Solder - DC - AMPLIMITE HD-20 Series - Metal Body. ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 5745784-4 is a 37-position 2-row standard right angle D-sub Receptacle with gold-plated phosphor bronze contacts, UL94V-0-rated black thermoplastic housing and 4-40 UNC zinc-plated threaded inserts. The HD-20 series right-angle posted connector has tin-plated carbon steel shell, tin-plated brass eyelet and grounding straps.

Product Highlights:

  • Number of Positions = 37
  • Receptacle
  • PCB Mount Angle = Right Angle
  • Product Series = HD 20
  • With Mating Connector Lock

Search Keywords: 57457844

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5745784-4
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
52
Package Type:
Tray
Type:
D-Subminiature
Body Orientation:
Right Angle
Mounting:
Through Hole
Gender:
SKT
Termination Method:
Solder
Shell Size:
4
Number of Contacts:
37
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 105 °C

IN STOCK: 1,053

Can Ship immediately

Minimum Order: 15

Factory Lead-Time 21 Weeks

Qty
Unit Price
15
$6.40
25
$3.83
52
$3.70
104
$3.56
260
$3.49
520
$3.45
1,040
$3.40
2,548 +
$3.39
Suppliers Standard Package
Log in for special pricing
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Accessories

1-747950-5

KIT,PLUG,37P,HDE,SHLD ENCLSRE

1658613-1

D Sub Connector - DB37 - 37 Contacts - Plug - IDC / IDT - DC - Amplimite HDF-20 Series - M ...

1-745498-5

37 HDE MS PLUG,22-26,LEAD FREE

1658608-1

D Sub Connector - DB37 - 37 Contacts - Plug - Crimp - DC - Amplimite HDF-20 Series - Metal ...

1-745498-6

PLUG ASSY,37P,HDE,MS

5747252-4

37 MSFL PLUG RA 318 (IN,FM)
