1658613-1 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

1658613-1

D Sub Connector - DB37 - 37 Contacts - Plug - IDC / IDT - DC - Amplimite HDF-20 Series - Metal Body. ...

View Datasheet Ask the Datasheet
RoHS Compliant
TUBE Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The 1658613-1 is a 37-way 2-row IDC Standard D-sub Plug for flat ribbon cable. It has phosphor bronze contacts and standard mounting holes. This Amplimite HDF-20 series low profile connector comes with tin-plated steel shell, thermoplastic housing and tin over nickel plated solder tail. It accepts 28 to 26AWG wire.

Product Highlights:

  • Connector
  • Product Series = HDF-20 (Ribbon Cable)
  • Number of Positions = 37
  • Plug
  • With Contacts

Search Keywords: 16586131

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1658613-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694051
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
40
Package Type:
TUBE
Type:
D-Subminiature
Body Orientation:
Right Angle
Mounting:
Cable Mount
Gender:
Pin
Termination Method:
IDT
Shell Size:
4
Number of Contacts:
37
Contact Plating:
Gold Over Nickel,Gold Over Palladium Nickel Over Nickel
Operating Temperature:
-55 to 105 °C

FREQUENTLY ASKED QUESTIONS

Is 1658613-1 RoHS compliant?

Yes, 1658613-1 is RoHS compliant.

What is the lead time for 1658613-1?

The standard lead time for 1658613-1 is approximately 31 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 416

Can Ship immediately

On Order: 1,600   can ship 12/21/26

Minimum Order Quantity: 5

Factory Lead-Time 31 Weeks

Price (USD)

Qty
Unit Price
5
$10.46
40
$10.24
80
$10.14
120
$9.83
280
$9.48
520
$9.34
1,000 +
$8.98
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request
