5100147-1 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

5100147-1

Backplane Connector - Receptacle - Female Sockets - 110 Position - 5 Rows - 0.079" (2.00mm) Pitch - Press-Fit - Board Edge, Through Hole, Right Angle. ...

View Datasheet Ask the Datasheet
RoHS Compliant
TUBE Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The 5100147-1 from TE Connectivity / AMP Brand is board edge, through hole mounting, right angle backplane connector Z-PACK series, receptacle with female sockets, 110 positions, 5 rows, 0.079" (2.00mm) pitch and press-fit termination. Operating temperature range is from -55 to 125 °C ( -67 to 257 °F ).

Product Highlights:

  • Connector
  • Connector Type = Type A
  • Receptacle
  • Interface Type = 2mm HM
  • Contact Type = Signal

Search Keywords: 51001471

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5100147-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
11
Package Type:
TUBE
Type:
Hard Metric
Gender:
RCP
Body Orientation:
Right Angle
Mounting:
Through Hole
Pitch:
2 mm
Number of Contacts:
110
Termination Method:
PRESS FIT
Operating Temperature:
-55 to 125 °C

FREQUENTLY ASKED QUESTIONS

Is 5100147-1 RoHS compliant?

Yes, 5100147-1 is RoHS compliant.

What is the lead time for 5100147-1?

The standard lead time for 5100147-1 is approximately 7 days. In-stock quantities ship from Master Electronics.

IN STOCK: 109

Can Ship immediately

Manufacturer Stock: 330   can ship 8/28/26

Minimum Order Quantity: 11

Multiple: 11

Factory Lead-Time 7 Weeks can ship 10/1/26

Price (USD)

Qty
Unit Price
1
$9.724
11
$8.840
33
$7.910
55
$7.890
110
$7.430
253
$7.100
506
$6.730
1,001 +
$6.410
Supplier's Standard Package
