ADF0804

Switch DIP OFF ON SPST 8 Flush Slide 0.1A 24VDC PC Pins 2.54mm Thru-Hole Tube ...

View Datasheet
RoHS Compliant
BAG Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The ADF0804 is a DIP switch designed for standard switching applications with a flush slide actuator and through-hole PCB mounting. It features a single pole-single throw (SPST) configuration, making it suitable for simple on/off switching operations. The switch utilizes a copper alloy contact base with gold flash plating on the mating area to ensure reliable electrical contact and corrosion resistance. The housing is constructed from polypropylene sulfide (PPS) in black, with a centerline spacing of 2.54 mm (0.100 inches), and is auto-insertable for efficient assembly. This DIP switch is commonly used in consumer electronics, industrial control panels, and embedded systems where compact, reliable switching functionality is required.

Product Highlights:

  • DIP Switch
  • PCB Mount Style = Through Hole
  • Single Pole - Single Throw Configuration (Pole-Throw)
  • Actuator Style = Flush, Slide
  • Not Sealed

Search Keywords: ADF0804

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Alcoswitch Brand
Part No:
ADF0804
Alias/AKA:
1-1825002-3
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509032
COO:
MY
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Package Type:
BAG
Body Orientation:
Straight
Actuator Style:
Flush Slide
Actuator Length:
0 mm
Number of Positions:
8
Pole Throw Configuration:
SPST
Mounting:
Through Hole
Terminal Type:
PC Pins
Contact Rating @ Voltage:
0.1@24VDC A
Contact Plating:
Gold Flash/Nickel
Terminal Pitch:
2.54 mm

FREQUENTLY ASKED QUESTIONS

Is ADF0804 RoHS compliant?

Yes, ADF0804 is RoHS compliant.

What is the lead time for ADF0804?

The standard lead time for ADF0804 is approximately 20 days. In-stock quantities ship from Master Electronics.

IN STOCK: 3,900

Can Ship immediately

Minimum Order Quantity: 20

Multiple: 20

Factory Lead-Time 20 Weeks

Price (USD)

Qty
Unit Price
20
$1.387
260
$1.203
500
$1.156
1,000
$1.106
2,500
$1.041
5,000
$0.806
7,500
$0.782
10,000 +
$0.683
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
