782XBXC-12D by schneider electric-legacy relays
Image is representational - see mfr. specs

782XBXC-12D

Schneider Electric-Legacy Relays

Power relay - SE Relays - 15A - DPDT - 12 VDC - clear cover ...

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Discontinued & Replaced
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The Magnecraft / Schneider Electric 782XBXC-12D is a high-quality electromechanical relay designed for optimal performance and durability. With a coil voltage of 12VDC and a resistance of 160 Ohm, this relay is suitable for a wide range of applications. It features a DPDT (Double Pole Double Throw) configuration, which allows for versatile switching options. Measuring at approximately 27.9 x 21 x 42.9mm, this relay is compact and space-saving, making it ideal for various industrial and commercial settings. It is capable of handling a maximum current of 15A, ensuring reliable power switching. The 782XBXC-12D relay is designed to be used with a socket, providing easy installation and maintenance. With the trusted brand of Magnecraft / Schneider Electric, you can rely on the quality and performance of this power relay for your application needs.

Search Keywords: 782XBXC12D

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Schneider Electric-Legacy Relays
Part No:
782XBXC-12D
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
DPDT
Maximum Current Rating:
15 A
Mounting:
Socket
Termination Style:
0.187Quick Connect
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 70 °C
Coil Resistance:
160 Ohm
Life Cycle:
Discontinued & Replaced
  This product is discontinued, but still in stock

IN STOCK: 683

Ships today, if you order in

On Order: 100   can ship 6/3/26

Minimum Order Quantity: 10

Multiple: 10

Qty
Unit Price
10
$22.06
30
$20.39
50
$20.33
100
$19.74
250
$19.16
500
$15.37
1,000 +
$15.33
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Older Equivalent
W78RCSX-7
W78RCSX-7
VIEW PRODUCT

Tools/3D Models

Product Guides

Accessories

70-782D8-1

Conn Relay Socket SKT 8 POS Screw ST Panel Mount

70-459-1

Socket - General Purpose Relays - for 782 relays - DPDT - 8 pins - output screw clamp term ...
