1830651 by phoenix contact

1830651

Phoenix Contact

PCB headers - nominal current: 8 A - rated voltage (III/2): 160 V - nominal cross section: 1.5 mm² - number of positions: 8 - pitch: 3.81 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3.4 mm ...

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PHOENIX CONTACT part 1830651 is a PCB header that is designed for various electronic applications. It has a nominal current rating of 8 A and a rated voltage of 160 V (III/2). With a nominal cross-section of 1.5 mm², it offers reliable and efficient power transmission.This PCB header is equipped with 8 positions and has a pitch size of 3.81 mm, allowing for convenient and secure connections. The header comes in a vibrant green color, making it easy to identify and differentiate from other components.Featuring a contact surface with a tin coating, this header ensures excellent conductivity and corrosion resistance for long-lasting performance. The wave soldering mounting method simplifies the installation process and guarantees a stable connection.The pin layout of this header follows a linear pinning design, enabling straightforward and organized connections. Additionally, the solder pin has a diameter of 3.4 mm, ensuring a secure and robust solder joint.Overall, the PHOENIX CONTACT 1830651 PCB header is a reliable and efficient component, perfect for various electrical applications that require precise and secure connections.

Search Keywords: 1830651

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1830651
Alias/AKA:
MCV 1 5/ 8-GF-3 81
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Type:
Wire to Board
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
3.81 mm
Number of Contacts:
8
Maximum Voltage Rating:
160 V
Maximum Current Rating:
8 A
Termination Method:
Solder
Operating Temperature:
N/A

IN STOCK: 449

Ships today, if you order in

Minimum Order: 5

Factory Lead-Time 11 Weeks

Qty
Unit Price
5
$5.33
50
$4.44
100
$4.19
300
$3.96
500
$3.90
1,000
$3.81
2,500
$3.75
5,000 +
$3.69
Suppliers Standard Package
Log in for special pricing
