LPF-40-24 by mean well
Image is representational - see manufacturer specifications
MEAN WELL Authorized Distributor

LPF-40-24

AC-DC Single output LED driver Mix mode (CV+CC) - Output 24Vdc at 1.67A - cable output - No dimming function. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

LPF-40-24 is 40W IP67 waterproof constant voltage LED driver / power supply with universal AC input. These fully encapsulated IP67 waterproof LED drivers / power supplies have a built in active PFC function and a fully isolated plastic case. Suitable applications for these IP67 LED drivers / power supplies include LED lighting and moving applications and can be used in dry or damp locations. LPF-40-24 has a 5 year factory warranty.

Search Keywords: LPF4024

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
MEAN WELL
Part No:
LPF-40-24
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504409510
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Input/Output Type:
AC/DC8097
Style:
Enclosed
Type:
Constant Current/Voltage
Output Type:
Fixed
Dimming:
No
Maximum Output Power:
40 W
Output Voltage Range:
14.4 to 24.0 Vdc
Maximum Output Current:
1,670 mA (1.67 A)
Minimum AC Input Voltage:
90
Maximum AC Input Voltage:
305
Minimum DC Input Voltage:
127
Maximum DC Input Voltage:
431
Termination Style:
Wire Leads
Input Connector Type:
Stripped and Tinned
Output Connector Type:
Stripped and Tinned
Operating Temperature:
-40 to 80 °C
Safety Agency Approvals:
CB, CCC, CE, cRUus, ENEC 17, PSE, TUV
NEC Class:
2
IEC Class:
II
SELV:
Yes
LPS:
No
Warranty:
5 Years
Family:
LPF-40

FREQUENTLY ASKED QUESTIONS

What replaces LPF-40-24?

The recommended replacement for LPF-40-24 is HLN-40H-24AB from MEAN WELL, available from Master Electronics.

Is LPF-40-24 RoHS compliant?

Yes, LPF-40-24 is RoHS compliant.

What is the lead time for LPF-40-24?

The standard lead time for LPF-40-24 is approximately 19 days. In-stock quantities ship from Master Electronics.

IN STOCK: 366

Can Ship immediately

Factory Lead-Time 19 Weeks

Price (USD)

Qty
Unit Price
1
$25.50
5
$24.30
10
$23.20
20 +
$22.50
