HLN-40H-24AB by mean well
Image is representational - see mfr. specs

HLN-40H-24AB

MEAN WELL

AC/DC LED Pwr Sply - Const Curr/Volt - 40.1W - Adj/Dim:24 Vdc @ 1,670mA - Dim: 1-10Vdc/PWM/Resist

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
End of Life: Final orders must be placed by 06/30/2026
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

AC/DC LED Pwr Sply - Const Curr/Volt - 40.1W - Adj/Dim:24 Vdc @ 1,670mA - Dim: 1-10Vdc/PWM/Resist

Search Keywords: HLN40H24AB

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
MEAN WELL
Part No:
HLN-40H-24AB
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504409510
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Input/Output Type:
AC/DC8097
Style:
Enclosed
Type:
Constant Current/Voltage
Output Type:
Adjustable,Dimmable
Dimming:
1 to 10 Vdc/PWM/Resistance
Maximum Output Power:
40 W
Output Voltage Range:
14.4 to 24.0 Vdc
Maximum Output Current:
1,670 mA (1.67 A)
Minimum AC Input Voltage:
90
Maximum AC Input Voltage:
305
Minimum DC Input Voltage:
127
Maximum DC Input Voltage:
431
Termination Style:
Wire Leads
Input Connector Type:
Stripped and Tinned
Output Connector Type:
Stripped and Tinned
Operating Temperature:
-40 to 50 °C
Safety Agency Approvals:
CB, CE, cRUus, EAC, PSE, TUV
NEC Class:
2
IEC Class:
None
SELV:
Yes
LPS:
No
Warranty:
3 Years
Family:
HLN-40H
End of Life:
Final orders must be placed by 06/30/2026
  End of Life: Final orders must be placed by 06/30/2026

IN STOCK: 78

Ships today, if you order in

MOQ for out of Stock Qty: 25

Factory Lead-Time 16 Weeks

Qty
Unit Price
1
$50.88
5
$50.11
10
$49.36
25
$48.62
50 +
$29.92
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
