ENS1J-B28-L00256L

Name: ENS1J-B28-L00256L Bourns Panel Mount Encoders
Brand: Bourns
SKU: 10751124
Availability: InStock

Optical Encoder - 6.35 mm Round Shaft - Incremental - 256 Cycle - 5V - Bracket Mount. ...

View Datasheet

Ask the Datasheet

RoHS Compliant

OTHER Packaging

Certificate of Compliance

DESCRIPTION

The ENS1J-B28-L00256L is a Rotary Optical Encoder with axial multi-purpose pin terminals and 2-bit quadrature code, channel A leads channel B by 90° (electrical) switching configuration with clockwise rotation. The rotary optical encoder has Ø1/4-inch plain end shaft and 9:00 position anti-rotation lug position. The self-contained rotary optical encoder is suitable for digital systems where both magnitude and direction of adjustment must be provided. The EN encoder is ideal for use as a digital panel control or as a position sensing device in applications where long life, reliability, high resolution and precise linearity are critical. Operating temperature range from -40°C to 75°C.

Product Highlights:

Potential Applications:

Search Keywords: ENS1JB28L00256L

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Bourns

Part No:

ENS1J-B28-L00256L

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8543903500

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
