GS101201 by zf electronic systems
图片仅供参考 - 请查看制造商规格
ZF Electronic Systems 授权经销商

GS101201

Hall Effect Sensor 25mA 9V/12V/15V/18V 3-Pin ...

查看数据表 询问数据表
符合 RoHS
BOX 包装
附件
请求编程报价
合规证书

描述

The ZF Electronics Corp GS101201 is a versatile Hall Effect Sensor designed to measure magnetic fields with exceptional accuracy and reliability. It operates at a maximum current of 25mA and can be powered by 9V, 12V, 15V, or 18V power supply. With its 3-pin configuration, this sensor offers easy installation and integration into various industrial applications. Whether used for position sensing, speed detection, or current sensing, the GS101201 ensures precise measurements and consistent performance. Trust in ZF Electronics Corp to provide top-notch sensor solutions for your engineering needs.

产品亮点:

  • Capable of operating upto 150?C
  • Sealed design exceedsIEC60529 IP67 standardfor immersion
  • Resistant to fuels, solvents,and lubricants associated withengines, transmissions, brakesand chassis systems
  • Easily customizable connectororientation
  • ESD resistant to 15kV(contact discharge)
  • Operates at arbitrarilylow speeds
  • Mating connector Delphi12162280

搜索关键词: GS101201

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
ZF Electronic Systems
部件编号:
GS101201
计量单位:
每 Each
RoHS:
Yes
HTS:
8543704000
COO:
MX
ECCN:
EAR99
供应商标准包装: 供应商原始包装中所含物品的数量、长度、重量或体积，以便高效存储、搬运和配送。
50
封装类型:
BOX
磁性类型:
Unipolar
最大输出电流:
25 mA
安装方式:
Screw
输出类型:
Sink
输出驱动器:
NPN
产品类型:
Digital
尺寸:
23.88 x 41.5 x 59.74 mm
典型工作电源电压:
5 to 24 V
端接类型:
Connector
工作温度:
-40 to 125 °C

常见问题

GS101201 是否符合 RoHS 标准？

是的，GS101201 符合 RoHS 标准。

GS101201 的交货期是多少？

GS101201 的标准交货期约为 20 周。有库存的数量由 Master Electronics 发货。

有存货: 1,520

可立即发货

工厂交货期 20 周

价格 (USD)

数量
单价
1
$31.18
50
$26.55
100
$24.69
250
$24.62
500
$24.56
750
$24.50
1,000 +
$24.44
