DB1C-B1RC by zf electronic systems
图片仅供参考 - 请查看制造商规格
ZF Electronic Systems 授权经销商

DB1C-B1RC

The DB1C-B1RC is a subminiature snap action switch from the DB series, rated for 6A at 250VAC and equipped with quick-connect terminals. ...

查看数据表 询问数据表
符合 RoHS
BOX 包装
附件
请求编程报价
合规证书

描述

The DB1C-B1RC is a subminiature snap action switch designed for applications requiring high precision and repeat accuracy. This switch has an electrical rating of 6A at 250VAC per EN61058-1 and 5A at 125/250VAC per UL1054. It features 2.8 x 0.5mm quick-connect (QC) terminals and requires a maximum operating force of 55 cN. The switch is specified with a maximum pretravel of 4.5 mm and a minimum overtravel of 2.0 mm. As part of the DB1 series, it offers a long mechanical life of up to 15 million cycles, making it a durable and reliable component for various industrial and commercial equipment.

搜索关键词: DB1CB1RC

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
ZF Electronic Systems
部件编号:
DB1C-B1RC
计量单位:
每 Each
RoHS:
Yes
HTS:
8536509040
COO:
CN
ECCN:
EAR99
供应商标准包装: 此信息提供给偏好按制造商标准包装数量的倍数购买的客户。最小订购数量和要求的订购倍数会与我们的价格和库存信息一起显示。
560
封装类型:
BOX
安装方式:
Through Hole
极-位配置:
SPDT
开关配置:
N.O./N.C.
致动器材质/样式:
Stainless Steel/Polybutylene Terephthalate/Roller Lever
触点额定电流 @ 电压:
6@250VAC@EN A
最大动作差:
0.6 mm
操作力:
0.54 N
端接方式:
Quick Connect
尺寸:
20 x 6.45 x 29.65 mm
本体方向:
Straight
IP等级:
IP50

FREQUENTLY ASKED QUESTIONS

Is DB1C-B1RC RoHS compliant?

Yes, DB1C-B1RC is RoHS compliant.

What is the lead time for DB1C-B1RC?

The standard lead time for DB1C-B1RC is approximately 30 days. In-stock quantities ship from Master Electronics.

有存货: 2,868

发货 today, 输入设置值。

最小订购数量: 25

工厂交货期 30 周

价格 (USD)

数量
单价
25
$2.06
100
$1.77
250
$1.75
560
$1.74
1,120
$1.73
2,800
$1.72
5,040
$1.71
7,840 +
$1.70
