2002-6304

The 2002-6304 is a blue, 3-conductor feed-through terminal block with a nominal cross-section of 2.5 mm² and Push-in CAGE CLAMP® connection technology. ...

查看数据表
符合 RoHS
包装
附件
请求编程报价
合规证书

描述

The 2002-6304 is a 3-conductor feed-through terminal block designed for reliable mounting on DIN-35 rails. It utilizes Push-in CAGE CLAMP® technology for connecting copper conductors from 0.25 mm² to 4 mm², requiring a strip length of 10 to 12 mm. According to IEC/EN 60947-7-1, it has a rated voltage of 800 V, a rated current of 24 A, and a rated impulse voltage of 8 kV. The terminal is made from Polyamide (PA66) with a V0 flammability rating and measures 5.2 mm in width. Suitable for both industrial and building applications, this terminal block is also approved for use in hazardous areas (Ex e II and Ex i), offering a secure and versatile connection solution.

搜索关键词: 20026304

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
WAGO
部件编号:
2002-6304
计量单位:
每 Each
RoHS:
Yes
HTS:
85369010000
COO:
CN
ECCN:
EAR99
供应商标准包装: 此信息提供给偏好按制造商标准包装数量的倍数购买的客户。最小订购数量和要求的订购倍数会与我们的价格和库存信息一起显示。
1

常见问题

2002-6304 是否符合 RoHS 标准？

是的，2002-6304 符合 RoHS 标准。

2002-6304 的交货期是多少？

2002-6304 的标准交货期约为 5 天。有库存的数量由 Master Electronics 发货。

有存货: 0

最小订购数量: 10

工厂交货期 5 周

价格 (USD)

数量
单价
10
$3.15
50
$2.93
250
$2.87
500
$2.81
1,000
$2.76
2,500
$2.70
5,000
$2.65
7,500 +
$2.59
登录以获取特别价格 点击询价 价格匹配请求
