BCN164AB473J7
Thick Film Chip Array - 4 Isolated Resistors - 47 kOhms ±5% 32mW per Element - ±200ppm/°C - SMD 1.6mm x 3.2mm - Tape&Reel ...
描述
BCN164AB473J7 is a thick film chip resistor array from the BCN Series, designed for space-efficient circuit designs requiring multiple resistors in a single package. This component features 4 isolated resistors with 47kO resistance value and ±5% tolerance (J), housed in a 1206 package size with 0603 equivalent chip array elements. The device has a width of 1.6mm, square convex edge termination, and dimensions of 3.20 ±0.10mm (L) × 1.60 ±0.10mm (W) × 0.50 ±0.10mm (H). It offers a power rating of 63mW per resistor (250mW per package) at 70°C and maximum operating voltage of 50Vdc. RoHS compliant and AEC-Q200 qualified, this resistor array is ideal for automotive and industrial applications where reliability and reduced board space are essential.
搜索关键词: BCN164AB473J7
规格
常见问题
BCN164AB473J7 是否符合 RoHS 标准？
是的，BCN164AB473J7 符合 RoHS 标准。
BCN164AB473J7 的交货期是多少？
BCN164AB473J7 的标准交货期约为 9 周。有库存的数量由 Master Electronics 发货。
