RAS18-6X

Sta-Con® Heat Shrinkable Ring Terminal - Wire Range #22-#18AWG - Material Copper - Tin-Plated Finish - Color Red - Bolt Hole #6 - Voltage Rating 600V ...

查看数据表 询问数据表
符合 RoHS
包装
附件
请求编程报价
合规证书

描述

The RAS18-6X is a ring terminal for wire range #22 - #18 AWG. These terminals are self-insulated with heat-shrinkable polyolefin and internally coated sealant. Upon completed installation, a fully sealed connection protects the joint against the degrading effects of galvanic action, corrosion, and environmental exposure - length 1.23 inches, width .25 inches, bolt hole #6, and maximum insulation .170 inches. The ring terminal is made of high-conductivity electrolytic copper, electro-tin plated. They recommended tool ERG4255.

搜索关键词: RAS186X

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
Thomas & Betts
部件编号:
RAS18-6X
计量单位:
每 Each
RoHS:
Yes
HTS:
8536904000
COO:
US
ECCN:
EAR99
供应商标准包装: 此信息提供给偏好按制造商标准包装数量的倍数购买的客户。最小订购数量和要求的订购倍数会与我们的价格和库存信息一起显示。
100

FREQUENTLY ASKED QUESTIONS

Is RAS18-6X RoHS compliant?

Yes, RAS18-6X is RoHS compliant.

What is the lead time for RAS18-6X?

The standard lead time for RAS18-6X is approximately 6 days. In-stock quantities ship from Master Electronics.

有存货: 303

发货 today, 输入设置值。

最小订购数量: 10

工厂交货期 6 周

价格 (USD)

数量
单价
10
$4.24
50
$3.45
100
$3.44
300
$3.20
500
$3.02
1,000
$3.01
2,500
$2.87
5,000 +
$2.83
供应商标准包装
登录以获取特别价格 点击询价 价格匹配请求

工具/3D模型

产品指南

附件

ERG4255

Manual Crimp Tool
