FN2090B-4-06 by te connectivity / schaffner emc
图片仅供参考 - 请查看制造商规格
TE Connectivity / SCHAFFNER EMC 授权经销商

FN2090B-4-06

The FN2090B-4-06 is a two-stage, medical-grade AC/DC EMI filter designed for chassis mounting with excellent attenuation performance. ...

查看数据表
符合 RoHS
BOX 包装
附件
请求编程报价
合规证书

描述

The FN2090B-4-06 is a two-stage, medical-grade (B type) AC/DC EMI filter designed to provide high differential and common-mode attenuation. It operates with a rated current of 4 A at 40°C and a rated voltage of 250 VAC/VDC across a frequency range of DC to 400 Hz. This filter is characterized by an inductance of 14 mH and a Cx capacitance of 0.33 µF. As a medical version, it is manufactured without Y-capacitors to achieve a leakage current of 0.00 mA. The filter is designed for easy chassis mounting and features Faston 6.3 x 0.8 mm terminals, making it ideal for medical equipment and other noise-sensitive applications where high filter performance and negligible leakage current are required.

搜索关键词: FN2090B406

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
TE Connectivity / SCHAFFNER EMC
部件编号:
FN2090B-4-06
别名/又称:
802511-SF
计量单位:
每 Each
RoHS:
Yes
HTS:
9018908000
COO:
TH
ECCN:
EAR99
供应商标准包装: 此信息提供给偏好按制造商标准包装数量的倍数购买的客户。最小订购数量和要求的订购倍数会与我们的价格和库存信息一起显示。
20
封装类型:
BOX

常见问题

FN2090B-4-06 是否符合 RoHS 标准？

是的，FN2090B-4-06 符合 RoHS 标准。

FN2090B-4-06 的交货期是多少？

FN2090B-4-06 的标准交货期约为 16 周。有库存的数量由 Master Electronics 发货。

有存货: 0

已订购: 40   可以发货 11/6/26

工厂交货期 16 周

价格 (USD)

数量
单价
1
$69.87
5
$49.32
20
$34.98
40
$31.87
60
$30.74
100
$29.39
260 +
$27.88
供应商标准包装
